37208-62A3-004PL

Active

3M (TC)

PCB RECEPTACLE, WIRE-TO-BOARD, 2 MM, 1 ROWS, 8 CONTACTS, THROUGH HOLE MOUNT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Technical Data Sheet EN

37208-62A3-004PL

Active

3M (TC)

PCB RECEPTACLE, WIRE-TO-BOARD, 2 MM, 1 ROWS, 8 CONTACTS, THROUGH HOLE MOUNT

Deep-Dive with AI

DocumentsDatasheet Technical Data Sheet EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	37208-62A3-004PL

Applications	Automotive, Medical, General Purpose, Lighting, Industrial
Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	0.203 Ám
Contact Finish Thickness - Mating	8 Áin
Contact Finish Thickness - Post	Flash
Contact Length - Post	0.102 in
Contact Length - Post	2.6 mm
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Female Socket
Current Rating (Amps)	3 A
Fastening Type	Latch Holder
Features	Board Guide
Insulation Color	Black
Insulation Height	13 mm
Insulation Height	0.512 in
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	8
Number of Positions Loaded	All
Number of Rows	2
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Row Spacing - Mating	6.5 mm
Row Spacing - Mating	0.256 in
Style	Board to Cable/Wire
Termination	Kinked Pin, Solder
Voltage Rating	32 V

37208 Series

Part	Contact Material	Number of Rows	Insulation Height	Insulation Height	Connector Type	Material Flammability Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Contact Finish - Mating	Number of Positions	Features	Contact Type	Mounting Type	Contact Shape	Voltage Rating	Fastening Type	Applications	Contact Length - Post	Contact Length - Post	Pitch - Mating [x]	Pitch - Mating [x]	Current Rating (Amps)	Contact Finish Thickness - Post	Insulation Material	Insulation Color	Style	Number of Positions Loaded	Contact Finish - Post	Row Spacing - Mating	Row Spacing - Mating
3M (TC) 37208-62A3-004PL	Copper Alloy	2	13 mm	0.512 in	Receptacle	UL94 V-0	0.203 Ám	8 Áin	Kinked Pin Solder	Gold	8	Board Guide	Female Socket	Through Hole	Square	32 V	Latch Holder	Automotive General Purpose Industrial Lighting Medical	0.102 in	2.6 mm	0.079 in	2 mm	3 A	Flash	Liquid Crystal Polymer (LCP)	Black	Board to Cable/Wire	All	Gold	6.5 mm	0.256 in
3M (TC) 37208-62M3-004	Copper Alloy	2	13 mm	0.512 in	Receptacle	UL94 V-0	0.203 Ám	8 Áin	Kinked Pin Solder	Gold	8		Female Socket	Through Hole	Square	32 V	Latch Holder	Automotive General Purpose Industrial Lighting Medical	0.102 in	2.6 mm	0.079 in	2 mm	3 A	Flash	Liquid Crystal Polymer (LCP)	Black	Board to Cable/Wire	All	Gold	6.5 mm	0.256 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2.56
		10	$ 2.33
		100	$ 2.05
		500	$ 1.80
Newark	Each	100	$ 2.91
		250	$ 2.56
		500	$ 2.49
		1000	$ 2.12

Description

General part information

37208 Series

3M™ mini-clamp socket, 372 Series (372XX-62) are boardmount connectors with right-angle solder tails that mate with the 3M Mini-Clamp Plug, 371 Series featuring IDC termination offer a time-saving, reliable and field-installable wiring solution. They are suitable for wiring applications using 3-4 wires 28 to 20AWG and requiring 32V, 3.0A max. Common applications are connecting sensors and switches to equipment.
