DX0507/GN/00

Active

BULGIN LIMITED

LED PANEL INDICATOR GREEN 2.2V

Search across all available documentation for this part.

Active

BULGIN LIMITED

LED PANEL INDICATOR GREEN 2.2V

Technical Specifications

Parameters and characteristics for this part

Part	Voltage	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [x]	Panel Cutout Shape	Current	Ingress Protection	Termination Style	Termination Style	Millicandela Rating	Type	Lamp Color	Ratings
BULGIN LIMITED DX0507/GN/00	2.2 V	0.48 in	12.1 mm	Round	25 mA	IP67	Wire Leads	5.9 "	100 mcd	LED	Green
BULGIN LIMITED DX0507/RD/12	12 V	0.48 in	12.1 mm	Round	30 mA	IP67	Wire Leads	5.9 "	2000 mcd	LED	Red	DC
BULGIN LIMITED DX0507/RD/00	1.85 V	0.48 in	12.1 mm	Round	30 mA	IP67	Wire Leads	5.9 "	2000 mcd	LED	Red
BULGIN LIMITED DX0507/RD/24	24 V	0.48 in	12.1 mm	Round	30 mA	IP67	Wire Leads	5.9 "	2000 mcd	LED	Red	DC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	40	$ 24.50
Newark	Each	1	$ 30.88

General part information

LED Panel Indicator Green 2.2V 25mA Wire Leads - 5.9" (150.00mm)

Technical documentation and resources
