858-XR8-103RKT4 - 858-XR8-103RKT4

858-XR8-103RKT4

Active
MH Connectors

SENSOR CONNECTOR, VULCON SERIES, M12, FEMALE, 8 POSITIONS, SOLDER SOCKET, RIGHT ANGLE CABLE MOUNT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet3D Product Image EN+3
858-XR8-103RKT4 - 858-XR8-103RKT4

858-XR8-103RKT4

Active
MH Connectors

SENSOR CONNECTOR, VULCON SERIES, M12, FEMALE, 8 POSITIONS, SOLDER SOCKET, RIGHT ANGLE CABLE MOUNT

Deep-Dive with AI

DocumentsDatasheet3D Product Image EN+3

Technical Specifications

Parameters and characteristics for this part

Specification858-XR8-103RKT4
ApplicationsIndustrial
Backshell Material, PlatingNickel, Brass
ColorSilver
Connector TypeReceptacle, Male Pins
Contact Finish - MatingGold
Contact Finish Thickness - Mating10 çin
Contact Finish Thickness - Mating0.25 çm
Contact MaterialBrass
Current Rating (Amps)0.5 A
FeaturesBackshell
Ingress ProtectionIP67 - Dust Tight, Waterproof
Insert MaterialPolybutylene Terephthalate (PBT)
Material Flammability RatingUL94 V-0
Mounting TypeFree Hanging (In-Line), Right Angle
Number of Positions8
Operating Temperature [Max]85 °C
Operating Temperature [Min]-40 °C
OrientationX
Primary MaterialMetal
Shell FinishNickel
Shell MaterialZinc Alloy
Shell Size - InsertM12-8
ShieldingShielded
TerminationSolder
Voltage Rating50 VAC, 60 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyTray 1$ 53.41
10$ 41.37
25$ 37.56
40$ 35.78
80$ 33.38
230$ 30.14
NewarkEach 100$ 31.14

Description

General part information

858-XR8 Series

8 Position Circular Connector Receptacle, Male Pins Solder
