MLPF-NRG-01D3

Active

STMicroelectronics

2.4 GHZ LOW PASS FILTER MATCHED TO STM32WB0 SERIES AND BLUENRG-LP-LPS (BLUENRG-3X5VX, BLUENRG-3X5AX, BLUENRG-332XX) IN QFN & CSP PACKAGES

Deep-Dive with AI

Search across all available documentation for this part.

Documents DS14044 +5

MLPF-NRG-01D3

Active

STMicroelectronics

2.4 GHZ LOW PASS FILTER MATCHED TO STM32WB0 SERIES AND BLUENRG-LP-LPS (BLUENRG-3X5VX, BLUENRG-3X5AX, BLUENRG-332XX) IN QFN & CSP PACKAGES

Deep-Dive with AI

Documents DS14044 +5

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	MLPF-NRG-01D3

Bandwidth	100 MHz
Filter Type [custom]	Low Pass
Frequency	2.45 GHz
Height (Max) [Max]	0.027 in
Height (Max) [Max]	0.68 mm
Insertion Loss	1.1 dB
Mounting Type	Surface Mount
Package / Case	CSPBGA, 6-WFBGA
Size / Dimension [x]	0.039 in
Size / Dimension [x]	1 mm
Size / Dimension [y]	0.063 in
Size / Dimension [y]	1.6 mm

MLPF-WB55-02E3 Series

2.4 GHz Low Pass Filter matched to STM32WB0 series and BLUENRG-LP-LPS (BLUENRG-3x5Vx, BLUENRG-3x5Ax, BLUENRG-332xx) in QFN & CSP packages

Part	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Filter Type [custom]	Insertion Loss	Height (Max) [Max]	Height (Max) [Max]	Bandwidth	Package / Case	Frequency	Height (Max) [Max] [z]	Height (Max) [Max] [z]
STMicroelectronics MLPF-NRG-01D3	Surface Mount	0.063 in	0.039 in	1 mm	1.6 mm	Low Pass	1.1 dB	0.027 in	0.68 mm	100 MHz	6-WFBGA CSPBGA	2.45 GHz
STMicroelectronics MLPF-WB-01E3	Surface Mount					Low Pass	0.9 dB				6-SMD No Lead	2.4 GHz
STMicroelectronics MLPF-WB55-02E3	Surface Mount	0.039 "	0.063 in	1.6 mm	1 mm	Low Pass	1.2 dB			100 MHz	6-SMD No Lead	2.45 GHz	0.016 in	0.4 mm
STMicroelectronics MLPF-WB-02D3	Surface Mount	0.063 in	0.039 in	1 mm	1.6 mm	Low Pass	1.2 dB	0.027 in	0.68 mm	100 MHz	6-WFBGA CSPBGA	2.45 GHz

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.36
		10	$ 0.29
		25	$ 0.27
		50	$ 0.26
		100	$ 0.24
		250	$ 0.22
		500	$ 0.21
		1000	$ 0.20
	Digi-Reel®	1	$ 0.36
		10	$ 0.29
		25	$ 0.27
		50	$ 0.26
		100	$ 0.24
		250	$ 0.22
		500	$ 0.21
		1000	$ 0.20
	Tape & Reel (TR)	5000	$ 0.17
		10000	$ 0.16
		15000	$ 0.15
		25000	$ 0.15
		35000	$ 0.14
		50000	$ 0.14

Description

General part information

MLPF-WB55-02E3 Series

The MLPF-NRG-01D3 integrates an impedance matching network and harmonics filter. The matching impedance network has been tailored to maximize the RF performances of STM32WB0 series and BLUENRG-LP-LPS (BLUENRG-3x5Vx, BLUENRG-3x5Ax, BLUENRG-332xx) in QFN and CSP packages. This device uses STMicroelectronics IPD technology on non-conductive glass substrate which optimizes RF performances.
