PM1038S-R39M-RC

Obsolete

Bourns Inc.

FIXED IND 390NH 24A 1.4 MOHM SMD

Search across all available documentation for this part.

Obsolete

Bourns Inc.

FIXED IND 390NH 24A 1.4 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Current - Saturation (Isat)	Tolerance	DC Resistance (DCR) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Mounting Type	Package / Case	Current Rating (Amps)	Inductance	Material - Core	Inductance Frequency - Test	Shielding
Bourns Inc. PM1038S-R75M-RC	28 A	20 %	2.5 mOhm	-55 °C	150 °C	0.165 in	4.2 mm	11.8 mm	0.465 in	0.413 in	10.5 mm	Surface Mount	Nonstandard	22 A	750 nH	Iron	100 kHz	Shielded
Bourns Inc. PM1038S-2R5M-RC	14 A	20 %	8.7 mOhm	-55 °C	150 °C	0.165 in	4.2 mm	11.8 mm	0.465 in	0.413 in	10.5 mm	Surface Mount	Nonstandard	11.5 A	2.5 µH	Iron	100 kHz	Shielded
Bourns Inc. PM1038S-R39M-RC	32 A	20 %	1.4 mOhm	-55 °C	150 °C	0.165 in	4.2 mm	11.8 mm	0.465 in	0.413 in	10.5 mm	Surface Mount	Nonstandard	24 A	390 nH	Iron	100 kHz	Shielded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

390 nH Shielded Inductor 24 A 1.4mOhm Max Nonstandard
