General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Gray 23 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 10GXS32008A1000 | 10GXS32 Series |
|---|---|---|
| Cable Type | Multi-Pair, Cat6a | Multi-Pair, Cat6a |
| Conductor Insulation | Polyolefin (PO) | Polyolefin (PO) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.278 in | 0.278 in |
| Jacket (Insulation) Diameter [diameter] | 7.06 mm | 7.06 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Gray | Green, Orange, Violet, Black, Red, Gray |
| Length | 1000 ft | 1000 ft |
| Length | 304.8 m | 304.8 m |
| Number of Conductors | 8 | 8 |
| Ratings | UL Style CMR | UL Style CMR |
| Usage | Network | Network |
| Voltage | 300 V | 300 V |
| Wire Gauge | 23 AWG | 23 AWG |
CAT6A 4PRB U/UTP CMR RIB
| Part | Jacket (Insulation) Material | Usage | Features | Conductor Strand | Length | Length | Conductor Insulation | Ratings | Number of Conductors | Cable Type | Voltage | Conductor Material | Wire Gauge | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GXS32005A1000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Green | 0.278 in | 7.06 mm |
Belden Inc. 10GXS32009A1000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | 0.278 in | 7.06 mm | |
Belden Inc. 10GXS32003A1000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Orange | 0.278 in | 7.06 mm |
Belden Inc. 10GXS32007A1000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Violet | 0.278 in | 7.06 mm |
Belden Inc. 10GXS32 0101000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Black | 0.278 in | 7.06 mm |
Belden Inc. 10GXS32 0021000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Red | 0.278 in | 7.06 mm |
Belden Inc. 10GXS32008A1000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Gray | 0.278 in | 7.06 mm |
Belden Inc. 10GXS32010A1000 | Poly-Vinyl Chloride (PVC), Riser | Network | Rip Cord | Solid | 1000 ft | 304.8 m | Polyolefin (PO) | UL Style CMR | 8 | Multi-Pair, Cat6a | 300 V | Copper, Bare | 23 AWG | Black | 0.278 in | 7.06 mm |
