1700/34EP 299'
Active3M
CBL RIBN 34COND TWIST PAIR 299'
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsCables & Accessories Selection Guide
1700/34EP 299'
Active3M
CBL RIBN 34COND TWIST PAIR 299'
Deep-Dive with AI
DocumentsCables & Accessories Selection Guide
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1700/34EP 299' | 1700 Series |
|---|---|---|
| Adhesive | - | Rubber |
| Backing, Carrier | - | PVC (Poly Vinyl Chloride) |
| Cable Type | Flat Twisted Pair | Flat Twisted Pair |
| Color | - | White, Green, Red, Blue, Black, Brown |
| Conductor Material | Copper, Tinned | Copper, Tinned |
| Conductor Strand [custom] | 7 | 7 |
| Conductor Strand [custom] | 36 AWG | 36 AWG |
| Features | - | Splice Free |
| Insulation Resistance | 1 GOhms | 1 GOhms |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Multiple | Multiple |
| Length | 91.14 m | 7.62 - 91.44 m |
| Length | 299 ft | 25 - 300 ft |
| Length | - | 10 - 100 ft |
| Length | - | 3.05 - 30.48 m |
| Length | - | 22 - 36 yds |
| Length | - | Enter Number of Feet in Order Quantity |
| Number of Conductors | 34 | 10 - 64 |
| Number of Conductors | - | 30 (15 Pair Twisted) |
| Operating Temperature [Max] | 105 ░C | 105 ░C |
| Operating Temperature [Min] | -20 C | -20 C |
| Pitch [x] | 0.05 in | 0.05 in |
| Pitch [x] | 1.27 mm | 1.27 mm |
| Ratings | UL Style 20462 | UL Style 20462 |
| Ribbon Thickness | 0.08 in | 0.08 in |
| Ribbon Thickness | 2.03 mm | 2.03 mm |
| Ribbon Width | - | 1 - 76.2 mm |
| Ribbon Width | - | 1.3 - 3 " |
| Ribbon Width | - | 25.4 mm |
| Ribbon Width | - | 0.5 " |
| Ribbon Width | - | 12.7 mm |
| Ribbon Width | - | 0.7 in |
| Ribbon Width | - | 17.78 mm |
| Ribbon Width [y] | 1.7 in | 0.8 - 3.2 in |
| Ribbon Width [y] | 43.18 mm | 20.32 - 81.28 mm |
| Shelf Life | - | 60 Months |
| Shelf Life Start | - | Date of Manufacture |
| Shielding | Unshielded | Unshielded |
| Spool Size | - | 30.48 m |
| Spool Size | - | 100 ft |
| Storage/Refrigeration Temperature | - | 27 °C |
| Storage/Refrigeration Temperature | - | 81 °F |
| Storage/Refrigeration Temperature | - | 10 °C |
| Storage/Refrigeration Temperature | - | 10 °C |
| Tape Type | - | Electrical, Electrical - Printed |
| Temperature Range | - | 80 °C |
| Temperature Range | - | 176 °F |
| Temperature Range | - | 0 °C |
| Temperature Range | - | 80 °C |
| Thickness | - | 0.18 mm |
| Thickness | - | 7.1 mils |
| Thickness | - | 0.0071 in |
| Usage | - | General Purpose |
| Voltage | 300 V | 300 V |
| Width | - | 0.75 in |
| Width | - | 19.05 mm |
| Width | - | 0.75 in |
| Width | - | 2 " |
| Width | - | 50.8 mm |
| Width | - | 25.4 mm |
| Width | - | 1 in |
| Wire Gauge | 28 AWG | 28 AWG |
1700 Series
3M TWISTED PAIR FLAT CABLE, 1700 SERIES, 1700/50BA, 100 FT
...
| Part | Insulation Resistance | Jacket (Insulation) Material | Ribbon Thickness | Ribbon Thickness | Ribbon Width | Ribbon Width | Voltage | Ratings | Length [x] | Length [x] | Jacket Color | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Number of Conductors | Shielding | Pitch [x] | Pitch [x] | Cable Type | Operating Temperature [Min] | Operating Temperature [Max] | Length | Length | Ribbon Width | Ribbon Width [y] | Ribbon Width [y] | Features | Ribbon Width [custom] | Ribbon Width [custom] | Ribbon Width [x] | Ribbon Width [x] | Shelf Life Start | Temperature Range | Temperature Range | Tape Type | Color | Usage | Width | Width | Width | Backing, Carrier | Shelf Life | Length | Number of Conductors | Thickness | Thickness | Thickness | Storage/Refrigeration Temperature [Max] | Storage/Refrigeration Temperature [Max] | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Min] | Width [y] | Width [y] | Length | Spool Size | Spool Size | Temperature Range [Min] | Temperature Range [Max] | Width [x] | Width [x] | Adhesive |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 63.5 mm | 2.5 " | 300 V | UL Style 20462 | 100 ft | 30.48 m | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 50 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | |||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 1 in | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 20 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 91.44 m | 300 ft | 25.4 mm | |||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 63.5 mm | 2.5 " | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 50 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 91.44 m | 300 ft | |||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 34 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 91.14 m | 299 ft | 1.7 in | 43.18 mm | |||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 34 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 91.44 m | 300 ft | 1.7 in | 43.18 mm | |||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 16 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 60.96 m | 200 ' | 0.8 in | 20.32 mm | Splice Free | ||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 34 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 91.44 m | 300 ft | 1.7 in | 43.18 mm | |||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 64 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 15.24 m | 50 ft | 3.2 in | 81.28 mm | Splice Free | ||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 63.5 mm | 2.5 " | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 50 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 91.44 m | 300 ft | Splice Free | ||||||||||||||||||||||||||||||||||||||||
1 GOhms | Poly-Vinyl Chloride (PVC) | 0.08 in | 2.03 mm | 1 in | 300 V | UL Style 20462 | Multiple | 28 AWG | 7 | 36 AWG | Copper, Tinned | 20 | Unshielded | 0.05 in | 1.27 mm | Flat Twisted Pair | -20 C | 105 ░C | 60.96 m | 200 ' | 25.4 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 15 | $ 381.92 | |
Description
General part information
1700 Series
Flat Ribbon Cable Multiple 34 (17 Pair Twisted) Conductors 0.050" (1.27mm) Flat Twisted Pair 299.0' (91.14m)
