Specification	MTAA-16W-A

Applications	Medical
Approval Agency	cURus, TUV, CE
Current - Output 1	2 A
Current - Output 2	400 mA
Current - Output 3	400 mA
Features	Universal Input, Adjustable Output, Remote Sense
Mounting Type	Chassis Mount
Number of Outputs	3
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	0 °C
Power (Watts)	20 W
Size / Dimension Height	1.62 in
Size / Dimension Length	6.5 in
Size / Dimension Width	4 in
Type	Linear
Voltage - Input (AC) Maximum	240 VAC
Voltage - Input (AC) Minimum	100 VAC
Voltage - Output 1	5 V
Voltage - Output 2	12 V
Voltage - Output 3	-12 V

MTAA-16 Series

Part	Size / Dimension Width	Size / Dimension Height	Size / Dimension Length	Efficiency	Current - Output 3	Voltage - Input (AC) Maximum	Voltage - Input (AC) Minimum	Mounting Type	Features	Current - Output 2	Voltage - Output 1	Applications	Operating Temperature (Max)	Operating Temperature (Min)	Current - Output 1	Type	Voltage - Output 2 (Min)	Voltage - Output 2 (Max)	Voltage - Output 3 (Max)	Voltage - Output 3 (Min)	Number of Outputs	Approval Agency	Voltage - Output 3	Voltage - Output 2	Power (Watts)
SL POWER / Advanced Energy MTAA-16W-AG	4 in	1.62 in	6.5 in	45 %	400 mA	240 VAC	100 VAC	Chassis Mount	Adjustable Output Remote Sense Universal Input	400 mA	5 V	Medical	70 °C	0 °C	2 A	Linear	12 V	15 V	15 V	-12 V	3	CE
SL POWER / Advanced Energy MTAA-16W-A	4 in	1.62 in	6.5 in		400 mA	240 VAC	100 VAC	Chassis Mount	Adjustable Output Remote Sense Universal Input	400 mA	5 V	Medical	70 °C	0 °C	2 A	Linear					3	CE cURus TUV	-12 V	12 V	20 W
