SRN5020TA-330M
ActiveBourns Inc.
IND,5X5X1.8MM,33.UH20%,0.80A,SEMI-SHDSMD /TAPE & REEL - 13" REEL
Deep-Dive with AI
Search across all available documentation for this part.
SRN5020TA-330M
ActiveBourns Inc.
IND,5X5X1.8MM,33.UH20%,0.80A,SEMI-SHDSMD /TAPE & REEL - 13" REEL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SRN5020TA-330M |
|---|---|
| Current - Saturation (Isat) | 800 mA |
| Current Rating (Amps) | 800 mA |
| DC Resistance (DCR) | 335 mOhm |
| Frequency - Self Resonant | 20 MHz |
| Height - Seated (Max) [Max] [z] | 2 mm |
| Height - Seated (Max) [Max] [z] | 0.079 in |
| Inductance | 33 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Q @ Freq | 15, 100 kHz |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension [x] | 0.197 in |
| Size / Dimension [x] | 5 mm |
| Size / Dimension [y] | 5 mm |
| Size / Dimension [y] | 0.197 " |
| Tolerance | 20 % |
| Type | Wirewound, Drum Core |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.46 | |
| 10 | $ 0.40 | |||
| 25 | $ 0.36 | |||
| 50 | $ 0.33 | |||
| 100 | $ 0.29 | |||
| 250 | $ 0.28 | |||
| 500 | $ 0.24 | |||
| 1000 | $ 0.21 | |||
| Digi-Reel® | 1 | $ 0.46 | ||
| 10 | $ 0.40 | |||
| 25 | $ 0.36 | |||
| 50 | $ 0.33 | |||
| 100 | $ 0.29 | |||
| 250 | $ 0.28 | |||
| 500 | $ 0.24 | |||
| 1000 | $ 0.21 | |||
| Tape & Reel (TR) | 2500 | $ 0.16 | ||
| Newark | Each (Supplied on Full Reel) | 1 | $ 0.23 | |
| 5000 | $ 0.23 | |||
| 10000 | $ 0.21 | |||
| 20000 | $ 0.19 | |||
| 30000 | $ 0.18 | |||
| 50000 | $ 0.17 | |||
Description
General part information
SRN5020TA Series
33 µH Shielded Drum Core, Wirewound Inductor 800 mA 335mOhm Nonstandard
