CPD250-4530CG

Active

Bel Power Solutions

DC/DC CNVRTR 5V 3.3V +/-12V 250W

Search across all available documentation for this part.

Active

Bel Power Solutions

DC/DC CNVRTR 5V 3.3V +/-12V 250W

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CPD250-4530CG	CPD250 Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CE, cCSAus, TUV	EN, CE, CSA, UL, cUL, TUV, cCSAus, cCSAus, CE, NEMKO
Current - Output (Max)	5.5 A, 2 A, 40 A	2 - 40 A
Efficiency	82.2 %	81.7 - 82.2 %
Mounting Type	Compact PCI®	Compact PCI®
Number of Outputs	4	4
Operating Temperature [Max]	50 °C	50 °C
Operating Temperature [Min]	-25 °C	-40 - -25 °C
Power (Watts)	250 W	250 - 422 W
Size / Dimension [x]	6.67 in	6.4 - 6.77 in
Size / Dimension [x]	169.5 mm	162.5 - 172 mm
Size / Dimension [y]	3.94 in	1.6 - 3.94 "
Size / Dimension [y]	100 mm	40.6 - 100 mm
Size / Dimension [z]	1.6 "	1.6 - 5.07 "
Size / Dimension [z]	40.6 mm	40.6 - 128.7 mm
Standard Number	-	60950-1
Type	Enclosed	Enclosed
Voltage - Input (Max) [Max]	75 V	75 V
Voltage - Input (Min) [Min]	36 V	36 V
Voltage - Output 1	5 V	5 V
Voltage - Output 2	3.3 V	3.3 V
Voltage - Output 3	12 V	12 V

DC/DC CNVRTR 5V 3.3V +/-12V 250W

Part	Current - Output (Max)	Voltage - Input (Max) [Max]	Approval Agency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Output 2	Number of Outputs	Power (Watts)	Voltage - Input (Min) [Min]	Voltage - Output 3	Mounting Type	Efficiency	Type	Applications	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Standard Number
Bel Power Solutions CPD250-4530G	2 A, 5.5 A, 40 A	75 V	CE, CSA, cUL, EN, TUV, UL	1.6 "	162.5 mm	128.7 mm	5.07 "	40.6 mm	6.4 in	3.3 V	4	250 W	36 V	12 V	Compact PCI®	82.2 %	Enclosed	ITE (Commercial)	5 V
Bel Power Solutions CPD250-4530CG	2 A, 5.5 A, 40 A	75 V	cCSAus, CE, TUV	3.94 in	169.5 mm	40.6 mm	1.6 "	100 mm	6.67 in	3.3 V	4	250 W	36 V	12 V	Compact PCI®	82.2 %	Enclosed	ITE (Commercial)	5 V	50 °C	-25 °C
Bel Power Solutions CPD250-4530AG	2 A, 5.5 A, 40 A	75 V	cCSAus, CE, NEMKO	1.6 "	172 mm	128.7 mm	5.07 "	40.6 mm	6.77 in	3.3 V	4	422 W	36 V	12 V	Compact PCI®	81.7 %	Enclosed	ITE (Commercial)	5 V	50 °C	-40 °C	60950-1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	60	$ 423.14

General part information

Enclosed DC DC Converter 4 Output 5V 3.3V 12V -12V 40A, 40A, 5.5A, 2A 75V Input

Technical documentation and resources

No documents available
