6XV18303DE30

Active

Siemens

CIRC CBL 2POS RCPT TO PLUG 0.98'

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

6XV18303DE30

Active

Siemens

CIRC CBL 2POS RCPT TO PLUG 0.98'

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	6XV18303DE30	6XV18303 Series

1st Connector Gender	Male Pins	Male Pins
1st Connector Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
1st Connector Number of Positions	2	2
1st Connector Number of Positions Loaded	All	All
1st Connector Orientation	B	B
1st Connector Shell Size - Insert	M12	M12
1st Connector Type	Receptacle	Receptacle
2nd Connector Gender	Female Sockets	Female Sockets
2nd Connector Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
2nd Connector Number of Positions Loaded	All	All
2nd Connector Orientation	B	B
2nd Connector Shell Size - Insert	M12	M12
2nd Connector Type	Plug	Plug
Assembly Configuration	Standard	Standard
Cable Material	Polyurethane (PUR)	Polyurethane (PUR)
Cable Type	Round	Round
Color	Green	Green
Length	-	1.64 - 49.2 ft
Length	-	1 - 500 m
Shielding	Shielded	Shielded

6XV18303 Series

CIRC CBL 2POS RCPT TO PLUG 9.84'

Part	1st Connector Type	2nd Connector Type	2nd Connector Number of Positions Loaded	1st Connector Mounting Type	Color	2nd Connector Mounting Type	1st Connector Gender	Cable Type	1st Connector Number of Positions	2nd Connector Shell Size - Insert	Cable Material	Length [x]	Length [x]	Assembly Configuration	2nd Connector Gender	1st Connector Orientation	2nd Connector Orientation	1st Connector Shell Size - Insert	Shielding	1st Connector Number of Positions Loaded
Siemens 6XV18303DH30	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)	9.84 ft	3 m	Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DN15	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)	49.2 ft	15 m	Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DH20	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)	6.56 ft	2 m	Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DE30	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)			Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DE50	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)	1.64 ft	500 mm	Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DN10	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)			Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DH10	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)	3.28 ft	1 m	Standard	Female Sockets	B	B	M12	Shielded	All
Siemens 6XV18303DH50	Receptacle	Plug	All	Free Hanging (In-Line)	Green	Free Hanging (In-Line)	Male Pins	Round	2	M12	Polyurethane (PUR)			Standard	Female Sockets	B	B	M12	Shielded	All

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 38.86

Description

General part information

6XV18303 Series

Circular Cable Assembly Shielded 0.98' (300.00mm)
