RR3405ALGRN

Active

E-Switch

SWITCH ROCKER SPST 10A 125V

Search across all available documentation for this part.

Active

E-Switch

SWITCH ROCKER SPST 10A 125V

Technical Specifications

Parameters and characteristics for this part

Specification	RR3405ALGRN

Actuator Marking	No Marking
Actuator Type	Paddle - Illuminated
Circuit	SPST
Color - Actuator/Cap	Black
Current Rating (Amps)	10 A
Illumination Type, Color	LED, Green
Illumination Voltage (Nominal)	2.4 VDC
Mounting Type	Panel Mount, Threaded Body with Nut
Panel Cutout Dimensions [diameter]	18 mm
Switch Function	On-Off
Termination Style	Solder Lug
Voltage Rating - AC	125 V

Part	Circuit	Color - Actuator/Cap	Mounting Type	Termination Style	Illumination Type, Color	Actuator Marking	Current Rating (Amps)	Illumination Voltage (Nominal)	Voltage Rating - AC	Actuator Type	Panel Cutout Dimensions [diameter]	Switch Function
E-Switch RR3405ALGRN	SPST	Black	Panel Mount Threaded Body with Nut	Solder Lug	Green LED	No Marking	10 A	2.4 VDC	125 V	Paddle - Illuminated	18 mm	On-Off

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Rocker Switch SPST 10A (AC) 125 V Panel Mount, Threaded Body with Nut
