1005935-1
ActiveTE Connectivity Measurement Specialties
ULTRASONIC TRANSDUCER
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1005935-1
ActiveTE Connectivity Measurement Specialties
ULTRASONIC TRANSDUCER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1005935-1 |
|---|---|
| Features | High Frequency |
| Mounting Type | User Defined |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 C |
| Package / Case | Piezo Film, Cantilever (Wafer) |
| Sensor Type | Vibration, Piezo Film |
| Termination | Connector |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 68.49 | |
| 10 | $ 57.67 | |||
| 25 | $ 54.07 | |||
| 100 | $ 52.27 | |||
Description
General part information
1005935 Series
Vibration, Piezo Film Sensor Voltage User Defined Connector
Documents
Technical documentation and resources
