EFM-471AL

Active

East Electronics

BUZZER 24V 37.8MM WIRE

Search across all available documentation for this part.

Active

East Electronics

BUZZER 24V 37.8MM WIRE

Technical Specifications

Parameters and characteristics for this part

BUZZER 24V 37.8MM WIRE

Part	Termination	Operating Mode	Height - Seated (Max)	Height - Seated (Max) [Max]	Frequency	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage Range [Max]	Voltage Range [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Sound Pressure Level (SPL)
East Electronics EFM-471AL	Wire Leads	Continuous	14.3 mm	0.563 in	3.7 kHz	24 VDC	1.488 in	37.8 mm	30 V	18 VDC	-20 C	70 °C	Wire Lead	90 dB

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Buzzers 24 V 20mA 3.7kHz 90dB @ 24V, 30cm Wire Lead Wire Leads

Technical documentation and resources
