PAM8013AKR
ActiveDiodes Inc
3W MONO CLASS D WITH SMALLER PACKAGE
Deep-Dive with AI
Search across all available documentation for this part.
PAM8013AKR
ActiveDiodes Inc
3W MONO CLASS D WITH SMALLER PACKAGE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PAM8013AKR |
|---|---|
| Features | Short-Circuit, Thermal Protection, Depop |
| Max Output Power x Channels @ Load | 3 W |
| Max Output Power x Channels @ Load [custom] | 1 |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 C |
| Operating Temperature [Min] | -25 °C |
| Output Type | 1-Channel (Mono) |
| Package / Case | 9-UFLGA |
| Supplier Device Package | U-FLGA1515-9 |
| Type | Class D |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.60 | |
| 10 | $ 0.52 | |||
| 25 | $ 0.48 | |||
| 100 | $ 0.39 | |||
| 250 | $ 0.36 | |||
| 500 | $ 0.30 | |||
| 1000 | $ 0.23 | |||
| Digi-Reel® | 1 | $ 0.60 | ||
| 10 | $ 0.52 | |||
| 25 | $ 0.48 | |||
| 100 | $ 0.39 | |||
| 250 | $ 0.36 | |||
| 500 | $ 0.30 | |||
| 1000 | $ 0.23 | |||
| Tape & Reel (TR) | 3000 | $ 0.17 | ||
Description
General part information
PAM8013 Series
TN1.pdf
Documents
Technical documentation and resources
