IPS-G4003-5

Obsolete

Sensata Technologies

SENSOR PRESSURE 0-400BARG 4-20MA

Search across all available documentation for this part.

Obsolete

Sensata Technologies

SENSOR PRESSURE 0-400BARG 4-20MA

Technical Specifications

Parameters and characteristics for this part

Specification	IPS-G4003-5

Accuracy	0.25 %
Applications	Industrial Automation
Features	Temperature Compensated, Amplified Output
Maximum Pressure	9427.45 PSI
Maximum Pressure	65000 kPa
Operating Pressure	5801.51 PSI
Operating Pressure	40000 kPa
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Output [Max]	20 mA
Output [Min]	4 mA
Output Type	Analog Current
Package / Case	Cylinder
Port Style	Threaded
Pressure Type	Vented Gauge
Termination Style	Connector
Voltage - Supply [Max]	32 VDC
Voltage - Supply [Min]	9 V

SENSOR PRESSURE 0-400BARG 4-20MA

Part	Package / Case	Termination Style	Pressure Type	Features	Port Style	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply [Min]	Voltage - Supply [Max]	Maximum Pressure	Maximum Pressure	Output Type	Accuracy	Operating Pressure	Operating Pressure	Output [Max]	Output [Min]	Applications
Sensata Technologies IPS-G4003-5	Cylinder	Connector	Vented Gauge	Amplified Output, Temperature Compensated	Threaded	-20 C	80 C	9 V	32 VDC	9427.45 PSI	65000 kPa	Analog Current	0.25 %	5801.51 PSI	40000 kPa	20 mA	4 mA	Industrial Automation

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

SENSOR PRESSURE 0-400BARG 4-20MA
