AM3IW-480512DH30NZ
Activeaimtec
DC DC CONVERTER 5V 12V 3W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM3IW-480512DH30NZ
Activeaimtec
DC DC CONVERTER 5V 12V 3W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM3IW-480512DH30NZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 125 mA, 300 mA |
| Efficiency | 78 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 10-SIP Module |
| Package / Case | 7 Leads |
| Power (Watts) | 3 W |
| Size / Dimension [x] | 27.5 mm |
| Size / Dimension [x] | 1.08 " |
| Size / Dimension [y] | 9.5 mm |
| Size / Dimension [y] | 0.37 " |
| Size / Dimension [z] | 12 mm |
| Size / Dimension [z] | 0.47 " |
| Supplier Device Package | SIP |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 [Max] | 12 V |
| Voltage - Output 1 [Min] | 5 V |
| Voltage - Output 2 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 15.06 | |
| 5 | $ 14.76 | |||
| 8 | $ 14.47 | |||
| 16 | $ 14.18 | |||
| 32 | $ 13.89 | |||
| 64 | $ 13.62 | |||
| 76 | $ 13.34 | |||
Description
General part information
AM3IW Series
Isolated Module DC DC Converter 2 Output 5 ~ 12V 12V 300mA, 125mA 18V - 75V Input
