PQME1-S5-S12-M

CUI Inc.

DC DC CONVERTER 12V 744MW

Deep-Dive with AI

Search across all available documentation for this part.

PQME1-S5-S12-M

CUI Inc.

DC DC CONVERTER 12V 744MW

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PQME1-S5-S12-M

Applications	ITE (Commercial)
Approval Agency	EN
Current - Output (Max) [Max]	62 mA
Efficiency	73 %
Features	SCP
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	8-SMD Module, 5 Leads
Power (Watts)	744 mW
Size / Dimension [x]	0.52 "
Size / Dimension [x]	13.2 mm
Size / Dimension [y]	0.33 "
Size / Dimension [y]	8.5 mm
Size / Dimension [z]	7.3 mm
Size / Dimension [z]	0.29 "
Standard Number	55024, 55032
Type	Isolated Module
Voltage - Input (Max) [Max]	5.25 V
Voltage - Input (Min) [Min]	4.75 V
Voltage - Isolation	3000 V
Voltage - Output 1	12 V

PQME1 Series

Part	Voltage - Input (Min) [Min]	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Applications	Voltage - Input (Max) [Max]	Efficiency	Standard Number	Type	Approval Agency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Current - Output (Max) [Max]	Package / Case	Mounting Type	Number of Outputs	Features	Voltage - Isolation
CUI Inc. PQME1-S5-S5-M	4.75 V	0.75 W	85 °C	-40 °C	5 V	ITE (Commercial)	5.25 V	72 %	55024 55032	Isolated Module	EN	0.33 "	7.3 mm	0.52 "	8.5 mm	0.29 "	13.2 mm	150 mA	8-SMD Module 5 Leads	Surface Mount	1	SCP	3000 V
CUI Inc. PQME1-S5-S3-M-TR	4.75 V	660 mW	85 °C	-40 °C	3.3 V	ITE (Commercial)	5.25 V	68 %	55024 55032	Isolated Module	EN	0.33 "	7.3 mm	0.52 "	8.5 mm	0.29 "	13.2 mm	200 mA	8-SMD Module 5 Leads	Surface Mount	1	SCP	3000 V
CUI Inc. PQME1-S5-S12-M-TR	4.75 V	744 mW	85 °C	-40 °C	12 V	ITE (Commercial)	5.25 V	73 %	55024 55032	Isolated Module	EN	0.33 "	7.3 mm	0.52 "	8.5 mm	0.29 "	13.2 mm	62 mA	8-SMD Module 5 Leads	Surface Mount	1	SCP	3000 V
CUI Inc. PQME1-S5-S5-M-TR	4.75 V	0.75 W	85 °C	-40 °C	5 V	ITE (Commercial)	5.25 V	72 %	55024 55032	Isolated Module	EN	0.33 "	7.3 mm	0.52 "	8.5 mm	0.29 "	13.2 mm	150 mA	8-SMD Module 5 Leads	Surface Mount	1	SCP	3000 V
CUI Inc. PQME1-S5-S12-M	4.75 V	744 mW	85 °C	-40 °C	12 V	ITE (Commercial)	5.25 V	73 %	55024 55032	Isolated Module	EN	0.33 "	7.3 mm	0.52 "	8.5 mm	0.29 "	13.2 mm	62 mA	8-SMD Module 5 Leads	Surface Mount	1	SCP	3000 V
CUI Inc. PQME1-S5-S9-M-TR	4.75 V	747 mW	85 °C	-40 °C	9 V	ITE (Commercial)	5.25 V	72 %	55024 55032	Isolated Module	EN	0.33 "	7.3 mm	0.52 "	8.5 mm	0.29 "	13.2 mm	83 mA	8-SMD Module 5 Leads	Surface Mount	1	SCP	3000 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	38	$ 4.20

Description

General part information

PQME1 Series

Isolated Module DC DC Converter 1 Output 12V 62mA 4.75V - 5.25V Input
