AN5870K

Obsolete

Panasonic Industrial Automation Sales

IC SWITCH VIDEO RGB 2:1 30SDIP

Search across all available documentation for this part.

Obsolete

Panasonic Industrial Automation Sales

IC SWITCH VIDEO RGB 2:1 30SDIP

Technical Specifications

Parameters and characteristics for this part

Specification	AN5870K

Applications	Video
Features	RGB
Mounting Type	Through Hole
Multiplexer/Demultiplexer Circuit	2:1
Number of Channels	4
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Package / Case	30-SDIP
Package / Case	10.16 mm
Package / Case	10.16 mm
Supplier Device Package	30-SDIP
Voltage - Supply, Single (V+) [Max]	5.25 V, 12.6 V
Voltage - Supply, Single (V+) [Min]	4.5 V, 10.5 V

Part	Package / Case	Package / Case	Package / Case	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Number of Channels	Mounting Type	Features	Applications	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Multiplexer/Demultiplexer Circuit
Panasonic Industrial Automation Sales AN5870K	30-SDIP	10.16 mm	10.16 mm	4.5 V 10.5 V	5.25 V 12.6 V	4	Through Hole	RGB	Video	30-SDIP	70 °C	-20 °C	2:1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Video Switch IC 4 Channel 30-SDIP
