UB01KW035D

Active

NKK Switches

INDICATOR SQ BLACK HSNG AMB LED

Search across all available documentation for this part.

Active

NKK Switches

INDICATOR SQ BLACK HSNG AMB LED

Technical Specifications

Parameters and characteristics for this part

Part	Lamp Color	Lens Style	Panel Cutout Shape	Current	Lens Transparency	Lens Color	Voltage	Type	Termination Style	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]
NKK Switches UB01KW035F-JF	Green	Square with Flat Top	Square	25 mA	Diffused	Green	2.1 V	LED
NKK Switches UB01KW035F-FF	Green	Square with Flat Top	Square	25 mA	Diffused	Green	2.1 V	LED	PC Pin
NKK Switches UB01KW035D	Amber	Square with Flat Top	Square	30 mA			2 V	LED		15.24 mm	0.6 in	15.24 mm	0.6 in
NKK Switches UB01KW035F	Green	Square with Flat Top	Square	25 mA			2.1 V	LED

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Amber 2V 30mA
