MA8334-001
ActiveMACOM Technology Solutions
IC RF SWITCH SPDT 1GHZ 844-001
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MA8334-001
ActiveMACOM Technology Solutions
IC RF SWITCH SPDT 1GHZ 844-001
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MA8334-001 |
|---|---|
| Circuit | SPDT |
| Frequency Range [Max] | 1 GHz |
| Frequency Range [Min] | 10 MHz |
| Impedance | 50 Ohms |
| Insertion Loss | 0.35 dB |
| Isolation | 24 dB |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -65 ░C |
| RF Type | General Purpose |
| Supplier Device Package | 844-001 |
| Test Frequency | 450 MHz |
| Topology | Reflective |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 14 | $ 134.75 | |
Description
General part information
MA8334 Series
RF Switch IC General Purpose SPDT 1 GHz 50Ohm 844-001
Documents
Technical documentation and resources
