SRF1306-501Y

Active

Bourns Inc.

CMC9.5X10.5X5.75MM,50035%0.4A,NON-SHDSMD /TAPE & REEL - 13" REEL

Search across all available documentation for this part.

Active

Bourns Inc.

CMC9.5X10.5X5.75MM,50035%0.4A,NON-SHDSMD /TAPE & REEL - 13" REEL

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Impedance @ Frequency	DC Resistance (DCR) (Max) [Max]	Inductance @ Frequency	Current Rating (Max) [Max]	Height (Max) [Max]	Height (Max) [Max]	Voltage Rating - DC	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Lines
Bourns Inc. SRF1306-501Y	0.413 in	9.5 mm	10.5 mm	0.374 in	1.2 kOhms	300 mOhm	100 kHz 500 µH	400 mA	6.05 mm	0.238 "	50 VDC	Surface Mount	-40 °C	105 ░C	2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

500 µH @ 100 kHz 2 Line Common Mode Choke Surface Mount 1.2 kOhms @ 1 MHz 400mA DCR 300mOhm
