AUIPS1021STRL

Obsolete

Infineon Technologies

AUIPS1021 - HITFET, AUTOMOTIVE S

Search across all available documentation for this part.

Obsolete

Infineon Technologies

AUIPS1021 - HITFET, AUTOMOTIVE S

Technical Specifications

Parameters and characteristics for this part

Specification	AUIPS1021STRL

Current - Output (Max) [Max]	4.8 A
Fault Protection	Over Temperature, Current Limiting (Fixed)
Grade	Automotive
Input Type	Non-Inverting
Interface	On/Off
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Output Configuration	Low Side
Output Type	N-Channel
Package / Case	D2PAK (2 Leads + Tab), TO-263AB, TO-263-3
Qualification	AEC-Q100
Ratio - Input:Output [custom]	1:1
Rds On (Typ)	20 mOhm
Supplier Device Package	D2PAK
Switch Type	General Purpose
Voltage - Load	36 V
Voltage - Supply (Vcc/Vdd)	False

Part	Input Type	Voltage - Load	Grade	Interface	Mounting Type	Output Type	Output Configuration	Number of Outputs	Rds On (Typ)	Fault Protection	Package / Case	Supplier Device Package	Ratio - Input:Output [custom]	Qualification	Operating Temperature [Max]	Operating Temperature [Min]	Switch Type	Current - Output (Max) [Max]
Infineon Technologies AUIPS1021R	Non-Inverting	36 V	Automotive	On/Off	Surface Mount	N-Channel	Low Side	1	20 mOhm	Current Limiting (Fixed) Over Temperature	DPAK (2 Leads + Tab) SC-63 TO-252-3	TO-252AA (DPAK)	1:1	AEC-Q100	150 °C	-40 °C	General Purpose	4.3 A
Infineon Technologies AUIPS1021	Non-Inverting	36 V	Automotive	On/Off	Through Hole	N-Channel	Low Side	1	20 mOhm	Current Limiting (Fixed) Over Temperature	TO-220-3	TO-220	1:1	AEC-Q100	150 °C	-40 °C	General Purpose	13.5 A
Infineon Technologies AUIPS1021STRL	Non-Inverting	36 V	Automotive	On/Off	Surface Mount	N-Channel	Low Side	1	20 mOhm	Current Limiting (Fixed) Over Temperature	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	D2PAK	1:1	AEC-Q100	150 °C	-40 °C	General Purpose	4.8 A
Infineon Technologies AUIPS1021S	Non-Inverting	36 V	Automotive	On/Off	Surface Mount	N-Channel	Low Side	1	20 mOhm	Current Limiting (Fixed) Over Temperature	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	D2PAK	1:1	AEC-Q100	150 °C	-40 °C	General Purpose	4.8 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	270	$ 1.11

General part information

Power Switch/Driver 1:1 N-Channel 4.8A D2PAK

Technical documentation and resources

No documents available
