VMS-40-36
ActiveCUI Inc.
AC/DC CONVERTER 36V 40W
Deep-Dive with AI
Search across all available documentation for this part.
VMS-40-36
ActiveCUI Inc.
AC/DC CONVERTER 36V 40W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | VMS-40-36 |
|---|---|
| Applications | Medical |
| Approval Agency | IEC, EN, TUV, UL, CB Scheme, SIQ |
| Current - Output 1 | 1.11 A |
| Efficiency | 88 % |
| Features | Universal Input |
| Minimum Load Required | False |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | 0 °C |
| Power (Watts) | 40 W |
| Size / Dimension [x] | 3 " |
| Size / Dimension [x] | 76.2 mm |
| Size / Dimension [y] | 2 in |
| Size / Dimension [y] | 50.8 mm |
| Size / Dimension [z] | 0.91 in |
| Size / Dimension [z] | 23.1 mm |
| Standard Number | 61000-3-3, 55024, 61000-6-2, 60601-1, 61000-6-1, 55032 Class B, 61204-3, 61000-3-2, 61000-6-3, 60950-1 |
| Type | Open Frame |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Isolation | 5.656 kV |
| Voltage - Output 1 | 36 V |
VMS-40 Series
| Part | Standard Number | Approval Agency | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input [Min] | Voltage - Input [Max] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Type | Efficiency | Power (Watts) | Number of Outputs | Applications | Voltage - Output 1 | Current - Output 1 | Minimum Load Required | Features | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CUI Inc. | 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61204-3 | CB Scheme EN IEC SIQ TUV UL | Chassis Mount | 70 °C | 0 °C | 90 VAC | 264 VAC | 0.91 in | 23.1 mm | 3 " | 2 in | 76.2 mm | 50.8 mm | Open Frame | 88 % | 40 W | 1 | Medical | 36 V | 1.11 A | Universal Input | 5.656 kV | |
CUI Inc. | 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61204-3 | CB Scheme EN IEC SIQ TUV UL | Chassis Mount | 70 °C | 0 °C | 90 VAC | 264 VAC | 0.91 in | 23.1 mm | 3 " | 2 in | 76.2 mm | 50.8 mm | Open Frame | 87 % | 40 W | 1 | Medical | 15 V | 2.67 A | Universal Input | 5.656 kV | |
CUI Inc. | 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61204-3 | CB Scheme EN IEC SIQ TUV UL | Chassis Mount | 70 °C | 0 °C | 90 VAC | 264 VAC | 0.91 in | 23.1 mm | 3 " | 2 in | 76.2 mm | 50.8 mm | Open Frame | 86 % | 40 W | 1 | Medical | 12 V | 3.34 A | Universal Input | 5.656 kV | |
CUI Inc. | 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61204-3 | CB Scheme EN IEC SIQ TUV UL | Chassis Mount | 70 °C | 0 °C | 90 VAC | 264 VAC | 0.91 in | 23.1 mm | 3 " | 2 in | 76.2 mm | 50.8 mm | Open Frame | 88 % | 40 W | 1 | Medical | 48 V | 834 mA | Universal Input | 5.656 kV | |
CUI Inc. | 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61204-3 | CB Scheme EN IEC SIQ TUV UL | Chassis Mount | 70 °C | 0 °C | 90 VAC | 264 VAC | 0.91 in | 23.1 mm | 3 " | 2 in | 76.2 mm | 50.8 mm | Open Frame | 76 % | 40 W | 1 | Medical | 3.3 V | 6 A | Universal Input | 5.656 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 34.02 | |
| 5 | $ 32.05 | |||
| 10 | $ 31.24 | |||
| 25 | $ 30.20 | |||
| 50 | $ 29.43 | |||
| 100 | $ 28.81 | |||
Description
General part information
VMS-40 Series
Open Frame AC DC Converters 1 Output 36V 90 ~ 264 VAC Input
