C3523.41.02

Active

Prysmian Group

CABLE COAX PLEN RG6 18AWG 1000'

Search across all available documentation for this part.

Active

Prysmian Group

CABLE COAX PLEN RG6 18AWG 1000'

Technical Specifications

Parameters and characteristics for this part

Specification	C3523.41.02

Cable Group	RG-6
Cable Type	Coaxial - Plenum
Conductor Material	Copper, Bare
Conductor Strand	Solid
Dielectric Diameter [diameter]	0.17 in
Dielectric Diameter [diameter]	4.32 mm
Impedance	75 Ohms
Jacket (Insulation) Diameter [diameter]	5.74 mm
Jacket (Insulation) Diameter [diameter]	0.226 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Length	304.8 m
Length	1000 ft
Shield Coverage	95 %, 100 %
Shield Material	Tinned, Flexfoil®, Copper
Shield Type	Foil, Braid
Usage	RF Signal, CATV, MATV
VoP, Velocity of Propagation	86
Wire Gauge	18 AWG

Part	Conductor Strand	Impedance	Dielectric Diameter [diameter]	Dielectric Diameter [diameter]	Jacket (Insulation) Material	Length	Length	VoP, Velocity of Propagation	Shield Type	Usage	Shield Coverage	Conductor Material	Shield Material	Wire Gauge	Cable Type	Cable Group	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]
Prysmian Group C3523.41.02	Solid	75 Ohms	0.17 in	4.32 mm	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	86	Braid Foil	CATV MATV RF Signal	95 % 100 %	Copper Bare	Copper Flexfoil® Tinned	18 AWG	Coaxial - Plenum	RG-6	5.74 mm	0.226 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Coaxial - Plenum Cable 18 AWG (0.82mm²) RG-6 1000.0' (304.80m) 75 Ohms
