UCC25660EVM-064
ObsoleteTexas Instruments
UCC25660 EVALUATION MODULE
UCC25660EVM-064
ObsoleteTexas Instruments
UCC25660 EVALUATION MODULE
Description
General part information
UCC25660EVM-064
UCC25660x - Power Supply with PFC 1, Non-Isolated Outputs Evaluation Board
Technical Specifications
Parameters and characteristics for this part
| Specification | UCC25660EVM-064 |
|---|---|
| Board Type | Fully Populated |
| Contents | Board |
| Current - Output | 15 A |
| Frequency - Switching | 100 kHz |
| Main Purpose | Power Supply with PFC |
| Non-Isolated Output Count | 1 count |
| Output Type | Non-Isolated |
| Regulator Topology | Half-Bridge |
| Supplied Contents | Board(s) |
| Total Output Count | 1 |
| Utilized IC / Part | UCC25660x |
| Voltage - Input (AC) Maximum | 265 VAC |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Input (Maximum) | 410 V |
| Voltage - Input (Minimum) | 365 V |
| Voltage - Output | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
