Specification	AM6TW-4812SZ

Applications	ITE (Commercial)
Approval Agency	CE
Current - Output (Max)	500 mA
Efficiency	82 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	24-DIP Module
Power (Watts)	6 W
Size / Dimension Height	0.4 in
Size / Dimension Length	1.25 in
Size / Dimension Width	0.8 in
Type	Isolated Module
Voltage - Input (Max)	72 V
Voltage - Input (Min)	18 V
Voltage - Isolation	1500 Vrns
Voltage - Output 1	12 V

AM6TW Series

Part	Mounting Type	Size / Dimension Width	Size / Dimension Length	Size / Dimension Height	Type	Voltage - Isolation	Current - Output (Max)	Voltage - Input (Min)	Voltage - Input (Max)	Number of Outputs	Voltage - Output 1	Approval Agency	Applications	Efficiency	Package / Case	Power (Watts)	Operating Temperature (Min)	Operating Temperature (Max)	Package Leads	Package Name	Voltage - Output 2
aimtec AM6TW-2409SH30-NZ	Through Hole	0.8 in	1.24 in	0.4 in	Isolated Module	3 kV	667 mA	9 V	36 V	1	9 V	cURus UL	ITE (Commercial)	85 %	24-DIP Module	6 W	-40 °C	85 °C
aimtec AM6TW-2405SH30-NZ	Through Hole	0.8 in	1.24 in	0.4 in	Isolated Module	3 kV	1.2 A	9 V	36 V	1	5 V	cURus	ITE (Commercial)	83 %		6 W	-40 °C	85 °C	7 Leads	24-DIP Module
aimtec AM6TW-2407SH35Z	Through Hole	0.84 in	1.27 in	0.41 in	Isolated Module	3500 Vrms	830 mA	9 V	36 V	1	7.2 V	CE	ITE (Commercial)	78 %	24-DIP Module	6 W	-40 °C	85 °C
aimtec AM6TW-2405SH35Z	Through Hole	0.8 in	1.25 in	0.4 in	Isolated Module	3500 Vrms	1.2 A	9 V	36 V	1	5 V	CE	ITE (Commercial)	81 %	24-DIP Module	6 W	-40 °C	85 °C
aimtec AM6TW-4824SZ	Through Hole	0.84 in	1.27 in	0.41 in	Isolated Module	1500 Vrns	250 mA	18 V	72 V	1	24 V	CE	ITE (Commercial)	83 %	24-DIP Module	6 W	-40 °C	85 °C
aimtec AM6TW-4812SZ	Through Hole	0.8 in	1.25 in	0.4 in	Isolated Module	1500 Vrns	500 mA	18 V	72 V	1	12 V	CE	ITE (Commercial)	82 %	24-DIP Module	6 W	-40 °C	85 °C
aimtec AM6TW-4824SH35Z	Through Hole	0.84 in	1.27 in	0.41 in	Isolated Module	3500 Vrms	250 mA	18 V	72 V	1	24 V	CE	ITE (Commercial)	83 %	24-DIP Module	6 W	-40 °C	85 °C
aimtec AM6TW-2424SZ	Through Hole	0.84 in	1.27 in	0.41 in	Isolated Module	1500 Vrns	250 mA	9 V	36 V	1	24 V	CE	ITE (Commercial)	82 %		6 W	-40 °C	85 °C	12 Leads	24-DIP Module
aimtec AM6TW-4812D-RZ	Through Hole	0.8 in	1.25 in	0.4 in	Isolated Module	1500 Vrns	250 mA	18 V	72 V	2	12 V	CE	ITE (Commercial)	83 %		6 W	-40 °C	85 °C	8 Leads	24-DIP Module	-12 V
aimtec AM6TW-4812SH35-VZ	Through Hole	0.8 in	1.25 in	0.4 in	Isolated Module	3500 Vrms	500 mA	18 V	72 V	1	12 V		ITE (Commercial)	77 %		6 W	-40 °C	71 °C	7 Leads	24-DIP Module

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

AM6TW-4812SZ | Datasheet
