SPB09C Series

Part	Voltage - Input (Min)	Power (Watts)	Voltage - Input (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Number of Outputs	Features	Voltage - Output 1	Package Leads	Package Name	Applications	Current - Output (Max)	Voltage - Isolation	Type	Size / Dimension Length	Size / Dimension Width	Size / Dimension Height	Approval Agency	Efficiency	Mounting Type
MEAN WELL USA Inc. SPB09C-15	36 V	9 W	75 V	90 °C	-40 °C	1	Remote On/Off	15 V	6 Leads	8-DIP Module	ITE (Commercial)	600 mA	1500 Vrns	Isolated Module	0.94 in	0.38 in	0.44 in	CE EAC UKCA	88 %	Through Hole
MEAN WELL USA Inc. SPB09C-05	36 V	8 W	75 V	90 °C	-40 °C	1	Remote On/Off	5 V	6 Leads	8-DIP Module	ITE (Commercial)	1.6 A	1500 Vrns	Isolated Module	0.94 in	0.38 in	0.44 in	CE EAC UKCA	85 %	Through Hole
MEAN WELL USA Inc. SPB09C-12	36 V	9 W	75 V	90 °C	-40 °C	1	Remote On/Off	12 V	6 Leads	8-DIP Module	ITE (Commercial)	750 mA	1500 Vrns	Isolated Module	0.94 in	0.38 in	0.44 in	CE EAC UKCA	88 %	Through Hole
MEAN WELL USA Inc. SPB09C-24	36 V	9 W	75 V	90 °C	-40 °C	1	Remote On/Off	24 V	6 Leads	8-DIP Module	ITE (Commercial)	375 mA	1500 Vrns	Isolated Module	0.94 in	0.38 in	0.44 in	CE EAC UKCA	89 %	Through Hole
