PQQ10W-Q24-S24-S

CUI Inc.

MODULE DC-DC 24VIN 1-OUT 24V 0.417A 10W 7-PIN SIP MODULE TUBE

Search across all available documentation for this part.

CUI Inc.

MODULE DC-DC 24VIN 1-OUT 24V 0.417A 10W 7-PIN SIP MODULE TUBE

Technical Specifications

Parameters and characteristics for this part

Part	Package / Case	Package / Case	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Current - Output (Max) [Max]	Voltage - Output 1	Voltage - Isolation	Approval Agency	Features	Power (Watts)	Mounting Type	Type	Number of Outputs	Voltage - Input (Min) [Min]	Efficiency	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]
CUI Inc. PQQ10W-Q24-S15-S	8-SIP Module	7 Leads	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	667 mA	15 V	1.5 kV	CE	Remote On/Off	10 W	Through Hole	Isolated Module	1	9 V	88 %	ITE (Commercial)	85 °C	-40 °C	36 V
CUI Inc. PQQ10W-Q24-S12-S	8-SIP Module	7 Leads	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	833 mA	12 V	1.5 kV	CE	Remote On/Off	10 W	Through Hole	Isolated Module	1	9 V	88 %	ITE (Commercial)	85 °C	-40 °C	36 V
CUI Inc. PQQ10W-Q24-S5-S	8-SIP Module	7 Leads	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	2 A	5 V	1.5 kV	CE	Remote On/Off	10 W	Through Hole	Isolated Module	1	9 V	88 %	ITE (Commercial)	85 °C	-40 °C	36 V
CUI Inc. PQQ10W-Q24-S24-S	8-SIP Module	7 Leads	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm		24 V	1.5 kV	CE	Remote On/Off	10 W	Through Hole	Isolated Module	1	9 V	88 %	ITE (Commercial)	85 °C	-40 °C	36 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 24V 417mA 9V - 36V Input
