Specification	5423-0.125-36

Adhesive	Rubber
Backing	UHMW Polyethylene
Carrier	UHMW Polyethylene
Color	Clear
Length (ft)	108 ft
Length (yd)	36 yd
Shelf Life	18 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature (Maximum)	80 °F
Storage/Refrigeration Temperature (Minimum)	60 °F
Tape Type	Polyethylene
Temperature Range (Max)	225 °F
Temperature Range (Min)	-30 °F
Thickness	0.0117 in
Thickness - Adhesive	0.0017 in
Thickness - Backing, Carrier	0.01 in
Usage	General Purpose
Width	0.13 in

5423 Series

Part	Storage/Refrigeration Temperature (Maximum)	Storage/Refrigeration Temperature (Minimum)	Shelf Life	Shelf Life Start	Thickness	Tape Type	Thickness - Backing, Carrier	Thickness - Adhesive	Backing	Carrier	Length (yd)	Length (ft)	Adhesive	Width	Temperature Range (Max)	Temperature Range (Min)	Color	Usage
3M (TC) 3M 5423 11" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	11 in	225 °F	-30 °F	Clear
3M (TC) 3M 5423 5.67" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	5.67 in	225 °F	-30 °F	Clear
3M (TC) 3M 5423 0.313" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	0.31 in	225 °F	-30 °F	Clear
3M (TC) 3M 5423 1.375" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	1.38 in	225 °F	-30 °F	Clear
3M (TC) 0.625-5-5423	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	5 yd	15 ft	Rubber	0.63 in	225 °F	-30 °F	Clear
3M (TC) 3M 5423 2.25" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	2.25 in	225 °F	-30 °F	Clear
3M (TC) 5423-0.5-5	80 °F	60 °F	18 Months	Date of Manufacture	0.0117 in	Polyethylene	0.01 in	0.0017 in	UHMW Polyethylene	UHMW Polyethylene	5 yd	15 ft	Rubber	12.7 mm	225 °F	-30 °F	Clear	General Purpose
3M (TC) 3M 5423 1.875" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	1.88 in	225 °F	-30 °F	Clear
3M (TC) 3M 5423 7" X 36YD	80 °F	60 °F	18 Months	Date of Manufacture	0.012 in	Polyethylene	0.01 in	0.002 in	UHMW Polyethylene	UHMW Polyethylene	36 yd	108 ft	Rubber	7 in	225 °F	-30 °F	Clear
3M (TC) 5423-0.75-5	80 °F	60 °F	18 Months	Date of Manufacture	0.0117 in	Polyethylene	0.01 in	0.0017 in	UHMW Polyethylene	UHMW Polyethylene	5 yd	15 ft	Rubber	0.75 in	225 °F	-30 °F	Clear	General Purpose
