C4062A.41.01

Active

Prysmian Group

CABLE 3COND 22AWG BLACK 1000'

Search across all available documentation for this part.

Active

Prysmian Group

CABLE 3COND 22AWG BLACK 1000'

Technical Specifications

Parameters and characteristics for this part

Specification	C4062A.41.01

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.176 in
Jacket (Insulation) Diameter [diameter]	4.47 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	3
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Usage	Control, Communication
Voltage	300 V
Wire Gauge	22 AWG

Part	Voltage	Cable Type	Conductor Material	Length	Length	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Insulation	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Usage	Wire Gauge	Jacket (Insulation) Material	Length [x]	Length [x]
Prysmian Group C4062A.30.10	300 V	Multi-Conductor	Copper Tinned	1000 ft	304.8 m	-20 C	80 C	Poly-Vinyl Chloride (PVC)	3	7	30 AWG	Gray	0.176 in	4.47 mm	Communication Control	22 AWG	Poly-Vinyl Chloride (PVC)
Prysmian Group C4062A.46.10	300 V	Multi-Conductor	Copper Tinned			-20 C	80 C	Poly-Vinyl Chloride (PVC)	3	7	30 AWG	Gray	0.176 in	4.47 mm	Communication Control	22 AWG	Poly-Vinyl Chloride (PVC)
Prysmian Group C4062A.18.10	300 V	Multi-Conductor	Copper Tinned			-20 C	80 C	Poly-Vinyl Chloride (PVC)	3	7	30 AWG	Gray	0.176 in	4.47 mm	Communication Control	22 AWG	Poly-Vinyl Chloride (PVC)	500 '	152.4 m
Prysmian Group C4062A.41.01	300 V	Multi-Conductor	Copper Tinned	1000 ft	304.8 m	-20 C	80 C	Poly-Vinyl Chloride (PVC)	3	7	30 AWG	Black	0.176 in	4.47 mm	Communication Control	22 AWG	Poly-Vinyl Chloride (PVC)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

3 Conductor Multi-Conductor Cable Black 22 AWG 1000.0' (304.8m)
