LC79HALEK

Active

Quectel

EVAL BOARD FOR LC79H

Search across all available documentation for this part.

Active

Quectel

EVAL BOARD FOR LC79H

Technical Specifications

Parameters and characteristics for this part

Specification	LC79HALEK

For Use With/Related Products	LC79H
Supplied Contents	Board(s)
Type	GNSS

Part	Sensitivity	Mounting Type	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]	Protocol	Serial Interfaces	Antenna Type	Frequency	RF Family/Standard	Operating Temperature [Max]	Operating Temperature [Min]	Supplied Contents	For Use With/Related Products	Type	Utilized IC / Part	Data Rate
Quectel LC79DBMD	-163 dBm	Surface Mount	26-SMD Module	1.9 V	1.7 V	Beidou Galileo GLONASS GNSS GPS	I2C SPI UART	Antenna Not Included	1.176 GHz 1.561 GHz 1.575 GHz 1.602 GHz	Navigation	85 °C	-40 °C
Quectel LC79DDEK													Board(s)	LC79D	GNSS
Quectel LC79HALEK													Board(s)	LC79H	GNSS
Quectel LC79DAEK													Board(s)	LC79D	GNSS
Quectel LC79HBAEK													Board(s)	LC79H	GNSS
Quectel LC79DCEK													Board(s)	LC79D	GNSS
Quectel LC79DAMD	-163 dBm	Surface Mount	26-SMD Module	1.9 V	1.7 V	Beidou Galileo GLONASS GNSS GPS	I2C SPI UART	Antenna Not Included	1.176 GHz 1.561 GHz 1.575 GHz 1.602 GHz	Navigation	85 °C	-40 °C				BCM47755	921.6 kbps

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LC79H - GNSS Evaluation Board
