C44BPF13470ZB0J

Active

KEMET

FILM CAPACITOR, POLYPROPYLENE, 1200V, 5% +TOL, 5% -TOL, 0.47UF, CHASSIS MOUNT

Search across all available documentation for this part.

Active

KEMET

FILM CAPACITOR, POLYPROPYLENE, 1200V, 5% +TOL, 5% -TOL, 0.47UF, CHASSIS MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	C44BPF13470ZB0J

Applications	Snubber
Capacitance	0.47 µF
Dielectric Material	Metallized, Polypropylene (PP)
ESR (Equivalent Series Resistance)	10 mOhm
Height - Seated (Max) [Max] [z]	62 mm
Height - Seated (Max) [Max] [z]	2.441 in
Lead Spacing	0.394 in
Lead Spacing	10 mm
Mounting Type	Chassis, Stud Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	25 mm
Size / Dimension [diameter]	0.984 "
Termination	Quick Connect - 0.110" (2.8mm)
Tolerance	5 %
Voltage Rating - AC	500 V
Voltage Rating - DC	1200 V
Voltage Rating - DC	1.2 kV

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - AC	Lead Spacing	Lead Spacing	Package / Case	Dielectric Material	Applications	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage Rating - DC	Voltage Rating - DC	ESR (Equivalent Series Resistance)	Termination	Tolerance	Capacitance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Mounting Type
KEMET C44BPF13470ZB0J	85 °C	-40 °C	500 V	0.394 in	10 mm	Radial Can	Metallized Polypropylene (PP)	Snubber	25 mm	0.984 "	1200 V	1.2 kV	10 mOhm	Quick Connect - 0.110" (2.8mm)	5 %	0.47 µF	62 mm	2.441 in	Chassis Stud Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	210	$ 16.74

General part information

0.47 µF Film Capacitor 500V 1200V (1.2kV) Polypropylene (PP), Metallized Radial, Can
