FFTP-17-D-18.00-01-F-N

Active

.050 X .050 C/L TWISTED PAIR FEM

Active

.050 X .050 C/L TWISTED PAIR FEM

Description

General part information

34 Position Cable Assembly Rectangular Socket to Socket 1.50' (457.20mm)

Parameters and characteristics for this part

Part	Number of Positions	Contact Finish Thickness	Pitch - Connector	Contact Finish	Cable Termination	Features	Connector Type	Shielding	Color	Length	Pitch - Cable	Number of Rows
Samtec Inc. FFTP-17-D-03.85-01-N-R	34	10 Ąin	0.05 in	Gold	IDC	Polarizing Key	Reversed Socket to Socket	Unshielded	Multiple Twisted Pair (Round)	0.321 ft	0.025 in	2
Samtec Inc. FFTP-17-D-18.00-01-N-R	34	10 Ąin	0.05 in	Gold	IDC	Polarizing Key	Reversed Socket to Socket	Unshielded	Multiple Twisted Pair (Round)	1.5 ft	0.025 in	2
Samtec Inc. FFTP-17-D-18.00-01-N	34	10 Ąin	0.05 in	Gold	IDC	Polarizing Key	Socket to Socket	Unshielded	Multiple Twisted Pair (Round)	1.5 ft	0.025 in	2
Samtec Inc. FFTP-17-D-03.85-01-N	34	10 Ąin	0.05 in	Gold	IDC	Polarizing Key	Socket to Socket	Unshielded	Multiple Twisted Pair (Round)	0.321 ft	0.025 in	2
Samtec Inc. FFTP-17-D-18.00-01-F-N	34	10 Ąin	0.05 in	Gold	IDC	Polarizing Key	Socket to Socket	Unshielded	Multiple Twisted Pair (Round)	1.5 ft	0.025 in	2
Samtec Inc. FFTP-17-D-03.85-01-F-N	34	10 Ąin	0.05 in	Gold	IDC	Polarizing Key	Socket to Socket	Unshielded	Multiple Twisted Pair (Round)	0.321 ft	0.025 in	2
