TSH251CX RFG
ActiveTaiwan Semiconductor Corporation
HALL EFFECT SENSOR 1MA LATCH 1.8V/2.5V/3.3V 3-PIN TSOT-23 T/R
Deep-Dive with AI
Search across all available documentation for this part.
TSH251CX RFG
ActiveTaiwan Semiconductor Corporation
HALL EFFECT SENSOR 1MA LATCH 1.8V/2.5V/3.3V 3-PIN TSOT-23 T/R
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | TSH251CX RFG |
|---|---|
| Current - Output (Max) [Max] | 1 mA |
| Current - Supply (Max) [Max] | 1.4 mA |
| Features | Temperature Compensated |
| Function | Omnipolar Switch |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | CMOS |
| Package / Case | SOT-23-3, TO-236-3, SC-59 |
| Polarization | Either |
| Supplier Device Package | SOT-23 |
| Technology | Hall Effect |
| Test Condition [Max] | 125 °C |
| Test Condition [Min] | -40 °C |
| Voltage - Supply [Max] | 3.5 V |
| Voltage - Supply [Min] | 1.65 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.45 | |
| 10 | $ 1.09 | |||
| 25 | $ 0.87 | |||
| 100 | $ 0.80 | |||
| 500 | $ 0.67 | |||
| 1000 | $ 0.60 | |||
| Digi-Reel® | 1 | $ 1.45 | ||
| 10 | $ 1.09 | |||
| 25 | $ 0.87 | |||
| 100 | $ 0.80 | |||
| 500 | $ 0.67 | |||
| 1000 | $ 0.60 | |||
| Tape & Reel (TR) | 3000 | $ 0.47 | ||
| 6000 | $ 0.45 | |||
Description
General part information
TSH251 Series
Digital Switch Omnipolar Switch CMOS Hall Effect SOT-23
Documents
Technical documentation and resources
No documents available
