45S101-102L5

Active

Rosenberger

CONN 1.0/2.3 PLG STR 50OHM CRIMP

Search across all available documentation for this part.

Active

Rosenberger

CONN 1.0/2.3 PLG STR 50OHM CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	45S101-102L5

Body Finish	Gold
Body Material	Brass
Cable Group	RG-174A, 316, 188A
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	1.0/2.3
Connector Type	Male Pin, Plug
Contact Termination	Crimp
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Push-Pull
Frequency - Max [Max]	6000 MHz
Housing Color	Gold
Impedance	50 Ohms
Includes	1 Ferrule, 1 Contact, 1 Connector
Mating Cycles	500
Mounting Type	Free Hanging (In-Line)
Number of Ports	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Shield Termination	Crimp
Voltage Rating	250 VDC

Part	Fastening Type	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Cable Group	Center Contact Material	Mating Cycles	Body Finish	Center Contact Plating	Voltage Rating	Dielectric Material	Includes	Frequency - Max [Max]	Impedance	Connector Style	Body Material	Housing Color	Mounting Type	Shield Termination	Contact Termination	Number of Ports
Rosenberger 45S101-102L5	Push-Pull	Male Pin Plug	-55 °C	125 °C	188A 316 RG-174A	Beryllium Copper	500	Gold	Gold	250 VDC	Polytetrafluoroethylene (PTFE)	1 Connector 1 Contact 1 Ferrule	6000 MHz	50 Ohms	1.0/2.3	Brass	Gold	Free Hanging (In-Line)	Crimp	Crimp	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1.0/2.3 Connector Plug, Male Pin 50 Ohms Free Hanging (In-Line) Crimp
