4965-0-00-34-00-00-33-0
ActiveMill-Max Manufacturing Corp.
CONN PIN RECEPT .236
Deep-Dive with AI
Search across all available documentation for this part.
4965-0-00-34-00-00-33-0
ActiveMill-Max Manufacturing Corp.
CONN PIN RECEPT .236
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 4965-0-00-34-00-00-33-0 |
|---|---|
| Contact Finish | Gold |
| Contact Finish Thickness | 50 µin |
| Contact Finish Thickness | 1.27 µm |
| Contact Material | Brass Alloy |
| Flange Diameter [diameter] | 0.05 in |
| Flange Diameter [diameter] | 1.27 mm |
| Insulation | Non-Insulated |
| Length - Above Flange [x] | 0.23 in |
| Length - Above Flange [x] | 5.84 mm |
| Length - Overall [x] | 0.236 in |
| Length - Overall [x] | 5.99 mm |
| Mounting Hole Diameter [diameter] | 0.61 mm |
| Mounting Hole Diameter [diameter] | 0.024 in |
| Mounting Type | Through Hole |
| Pin Size - Above Flange [diameter] | 0.51 mm |
| Pin Size - Above Flange [diameter] | 0.02 in |
| Terminal Style | Single End, Nail Head |
| Terminal Type | PC Pin |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.80 | |
| 10 | $ 0.67 | |||
| 25 | $ 0.64 | |||
| 50 | $ 0.63 | |||
| 100 | $ 0.60 | |||
| 250 | $ 0.55 | |||
| 500 | $ 0.49 | |||
| 1000 | $ 0.44 | |||
| 3000 | $ 0.40 | |||
Description
General part information
4965-0 Series
PC Pin Terminal Connector Through Hole Gold 0.020" (0.51mm) Dia
Documents
Technical documentation and resources
No documents available
