MSSA3350

Obsolete

TE Connectivity Raychem Cable Protection

SWITCH SLIDE 3P3T 300MA 125V

Search across all available documentation for this part.

Obsolete

TE Connectivity Raychem Cable Protection

SWITCH SLIDE 3P3T 300MA 125V

Technical Specifications

Parameters and characteristics for this part

Part	Circuit	Operating Force	Voltage Rating - AC	Actuator Length [x]	Switch Travel	Electrical Life	Termination Style	Contact Timing	Current Rating (Amps)	Switch Function	Actuator Type	Mechanical Life	Actuator Material	Contact Finish	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Features	Contact Material	Voltage Rating - DC
TE Connectivity Raychem Cable Protection MSSA3350	3P3T	470 gf	125 V	10.41 mm	2 mm	15000 Cycles	PC Pin	Shorting	300 mA	On-On-On	Standard	15000 Cycles	Polyester	Silver	Through Hole	85 °C	-20 C	Epoxy Sealed Terminals	Copper Alloy
TE Connectivity Raychem Cable Protection MSSA3350G	3P3T	470 gf	20 V	10.41 mm	2 mm	15000 Cycles	PC Pin	Shorting	0.4 VA	On-On-On	Standard	15000 Cycles	Polyester	Gold	Through Hole	85 °C	-20 C	Epoxy Sealed Terminals	Copper Alloy	20 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Slide Switch 3P3T Through Hole
