XVX4SUG36D

Active

SunLED

LED CBI 3X2MM QUAD GRN RA

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

XVX4SUG36D

Active

SunLED

LED CBI 3X2MM QUAD GRN RA

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	XVX4SUG36D

Color	Green (x 4)
Configuration	4 High
Current	10 mA
Lens Size [x]	3 mm
Lens Size [y]	2 mm
Lens Style	Rectangle with Flat Top
Lens Type	Diffused, Green
Millicandela Rating	5 mcd
Mounting Type	Through Hole, Right Angle
Viewing Angle	140 °
Voltage Rating	2 V
Wavelength - Peak	565 nm

XVX4SUG36 Series

Part	Current	Color	Voltage Rating	Lens Type	Lens Size [y]	Lens Size [x]	Mounting Type	Configuration	Lens Style	Viewing Angle	Wavelength - Peak	Millicandela Rating
SunLED XVX4SUG36D	10 mA	Green (x 4)	2 V	Diffused Green	2 mm	3 mm	Through Hole Right Angle	4 High	Rectangle with Flat Top	140 °	565 nm	5 mcd

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	660	$ 1.14

Description

General part information

XVX4SUG36 Series

LED Circuit Board Indicator LED Circuit Board Indicator 4 High Green (x 4) Diffused, Green 2V 10mA Rectangle with Flat Top 3.00mm x 2.00mm Through Hole, Right Angle

Documents

Technical documentation and resources
