M80-5710805

Active

Harwin Inc.

4+4 POS. MALE DIL 24-28AWG CABLE CONN. KIT, NO JACKSCREWS ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Harwin Inc.

4+4 POS. MALE DIL 24-28AWG CABLE CONN. KIT, NO JACKSCREWS ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Cable Termination	Contact Type	Number of Rows	Contact Finish Thickness	Contact Finish Thickness	Number of Positions	Color	Wire Gauge [Min]	Wire Gauge [Max]	Wire Type	Connector Type	Contact Finish	Pitch [x]	Pitch [x]	Row Spacing	Row Spacing	Mounting Type	Features
Harwin Inc. M80-5710605	Crimp	Male Pin	2	10 Áin	0.25 Ám	6	Black	24 AWG	28 AWG	Discrete	Header	Gold	0.079 in	2 mm	2 mm	0.079 in	Free Hanging (In-Line)
Harwin Inc. M80-5711205	Crimp	Male Pin	2	10 Áin	0.25 Ám	12	Black	24 AWG	28 AWG	Discrete	Header	Gold	0.079 in	2 mm	2 mm	0.079 in	Free Hanging (In-Line)
Harwin Inc. M80-5712405	Crimp	Male Pin	2	10 Áin	0.25 Ám	24	Black	24 AWG	28 AWG	Discrete	Header	Gold	0.079 in	2 mm	2 mm	0.079 in	Free Hanging (In-Line)	Jackscrews Polarizing Key
Harwin Inc. M80-5710805	Crimp	Male Pin	2	10 Áin	0.25 Ám	8	Black	24 AWG	28 AWG	Discrete	Header	Gold	0.079 in	2 mm	2 mm	0.079 in	Free Hanging (In-Line)	Jackscrews Polarizing Key

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

8 Position Rectangular Header Connector Crimp Gold 24-28 AWG
