AUIRS2332J
ObsoleteInfineon Technologies
IC GATE DRVR HALF-BRIDGE 44PLCC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AUIRS2332J
ObsoleteInfineon Technologies
IC GATE DRVR HALF-BRIDGE 44PLCC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AUIRS2332J |
|---|---|
| Channel Type | 3-Phase |
| Current - Peak Output (Source, Sink) [custom] | 500 mA |
| Current - Peak Output (Source, Sink) [custom] | 250 mA |
| Driven Configuration | Half-Bridge |
| Grade | Automotive |
| High Side Voltage - Max (Bootstrap) [Max] | 600 V |
| Input Type | Non-Inverting |
| Logic Voltage - VIL, VIH [custom] | 2.2 V |
| Logic Voltage - VIL, VIH [custom] | 0.8 V |
| Mounting Type | Surface Mount |
| Number of Drivers | 6 |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 32 Leads |
| Package / Case | 44-LCC (J-Lead) |
| Qualification | AEC-Q100 |
| Rise / Fall Time (Typ) [custom] | 80 ns |
| Rise / Fall Time (Typ) [custom] | 40 ns |
| Supplier Device Package | 44-PLCC, 32 Leads (16.58x16.58) |
| Voltage - Supply [Max] | 20 V |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AUIRS2332 Series
Half-Bridge Gate Driver IC Non-Inverting 44-PLCC, 32 Leads (16.58x16.58)
