C4AQJBW5450M36J

Active

KEMET

POWER FILM CAPACITOR, METALLIZED PP, RADIAL BOX - 4 PIN, 45 ΜF, ± 5%, DC LINK, THROUGH HOLE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet C4AQJBW5450M36J +3

C4AQJBW5450M36J

Active

KEMET

POWER FILM CAPACITOR, METALLIZED PP, RADIAL BOX - 4 PIN, 45 ΜF, ± 5%, DC LINK, THROUGH HOLE

Deep-Dive with AI

DocumentsDatasheet C4AQJBW5450M36J +3

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	C4AQJBW5450M36J

Applications	Automotive, DC Link, DC Filtering
Capacitance	45 µF
Dielectric Material	Metallized, Polypropylene (PP)
ESR (Equivalent Series Resistance)	2.5 mOhms
Features	Low ESL
Height - Seated (Max) [Max]	46.2 mm
Height - Seated (Max) [Max]	1.819 in
Lead Spacing	37.5 mm
Lead Spacing	1.476 in
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Package / Case	Radial - 4 Leads
Ratings	AEC-Q200
Size / Dimension [x]	1.654 in
Size / Dimension [x]	42 mm
Size / Dimension [y]	1.378 "
Size / Dimension [y]	35 mm
Termination	PC Pins
Tolerance	5 %
Voltage Rating - DC	700 VDC

C4AQJB Series

Part	Features	Dielectric Material	ESR (Equivalent Series Resistance)	Applications	Capacitance	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - DC	Ratings	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Termination	Package / Case	Mounting Type	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET C4AQJBW5450M36J	Low ESL	Metallized Polypropylene (PP)	2.5 mOhms	Automotive DC Filtering DC Link	45 µF	5 %	46.2 mm	1.819 in	105 ░C	-55 °C	700 VDC	AEC-Q200	1.378 "	1.654 in	35 mm	42 mm	PC Pins	Radial - 4 Leads	Through Hole	37.5 mm	1.476 in
KEMET C4AQJBU4880M18J	Low ESL	Metallized Polypropylene (PP)	7.5 mOhm	Automotive DC Filtering DC Link	8.8 µF	5 %	30.2 mm	1.189 "	105 ░C	-55 °C	700 VDC	AEC-Q200	1.693 in	1.654 in	43 mm	42 mm	PC Pins	Radial	Through Hole	37.5 mm	1.476 in
KEMET C4AQJBW5330M3HJ	Low ESL	Metallized Polypropylene (PP)	3.3 mOhms	Automotive DC Filtering DC Link	33 ÁF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200	0.945 in	1.634 "	24 mm	41.5 mm	PC Pins	Radial - 4 Leads	Through Hole	37.5 mm	1.476 in	1.74 in	44.2 mm
KEMET C4AQJBU4330M1WJ	Low ESL	Metallized Polypropylene (PP)	17 mOhm	Automotive DC Filtering DC Link	3.3 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200					PC Pins	Radial	Through Hole	27.5 mm	1.083 in	0.795 "	20.2 mm
KEMET C4AQJBW5300M3JJ	Low ESL	Metallized Polypropylene (PP)	3.6 mOhms	Automotive DC Filtering DC Link	30 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200	1.102 in	1.654 in	28 mm	42 mm	PC Pins	Radial - 4 Leads	Through Hole	37.5 mm	1.476 in	1.465 in	37.2 mm
KEMET C4AQJBW5500M3OJ	Low ESL	Metallized Polypropylene (PP)	2.3 mOhms	Automotive DC Filtering DC Link	50 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200	1.378 "	1.654 in	35 mm	42 mm	PC Pins	Radial - 4 Leads	Through Hole	37.5 mm	1.476 in	1.976 "	50.2 mm
KEMET C4AQJBW5750M3NJ	Low ESL	Metallized Polypropylene (PP)	3.1 mOhms	Automotive DC Filtering DC Link	75 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200	1.378 "	2.264 in	35 mm	57.5 mm	PC Pins	Radial - 4 Leads	Through Hole	52.5 mm	2.067 in
KEMET C4AQJBU5150M12J	Low ESL	Metallized Polypropylene (PP)	5.3 mOhms	Automotive DC Filtering DC Link	15 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200	0.866 in	1.24 in	22 mm	31.5 mm	PC Pins	Radial	Through Hole	27.5 mm	1.083 in	1.465 in	37.2 mm
KEMET C4AQJBU4560M1XJ	Low ESL	Metallized Polypropylene (PP)	10.7 mOhms	Automotive DC Filtering DC Link	5.6 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200	0.512 in	1.24 in	13 mm	31.5 mm	PC Pins	Radial	Through Hole	27.5 mm	1.083 in	0.992 in	25.2 mm
KEMET C4AQJBU5100M11J	Low ESL	Metallized Polypropylene (PP)	6.8 mOhms	Automotive DC Filtering DC Link	10 µF	5 %			105 ░C	-55 °C	700 VDC	AEC-Q200					PC Pins	Radial	Through Hole	27.5 mm	1.083 in	1.15 in	29.2 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	90	$ 9.20
Newark	Each	1	$ 13.03
		10	$ 12.06
		25	$ 11.90
		50	$ 11.73
		100	$ 10.43
		250	$ 9.39
		500	$ 9.13

Description

General part information

C4AQJB Series

45 µF Film Capacitor 700V Polypropylene (PP), Metallized Radial - 4 Leads
