TPS536C7B1RSLR
ActiveTexas Instruments
DUAL-CHANNEL D-CAP+™, PMBUS (N+M ≤ 12 PHASES) STEP-DOWN, MULTIPHASE PWM CONTROLLER 48-VQFN -40 TO 125
Deep-Dive with AI
Search across all available documentation for this part.

TPS536C7B1RSLR
ActiveTexas Instruments
DUAL-CHANNEL D-CAP+™, PMBUS (N+M ≤ 12 PHASES) STEP-DOWN, MULTIPHASE PWM CONTROLLER 48-VQFN -40 TO 125
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
Specification | TPS536C7B1RSLR | TPS536C7 Series |
---|---|---|
Clock Sync | True | True |
Control Features | Soft Start, Frequency Control, Enable, Ramp, Current Limit, Phase Control | Phase Control, Current Limit, Frequency Control, Ramp, Enable, Soft Start |
Duty Cycle (Max) [Max] | 50 % | 50 % |
Frequency - Switching [Max] | 2 MHz | 2 MHz |
Frequency - Switching [Min] | 300 kHz | 300 kHz |
Function | Step-Down | Step-Down |
Mounting Type | Surface Mount | Surface Mount |
Number of Outputs | 1 | 1 |
Operating Temperature [Max] | 125 °C | 125 °C |
Operating Temperature [Min] | -40 °C | -40 °C |
Output Configuration | Positive | Positive |
Output Type | - | Transistor Driver |
Package / Case | 48-VFQFN Exposed Pad | 48-VFQFN Exposed Pad |
Serial Interfaces | PMBus | PMBus |
Supplier Device Package | 48-VQFN (6x6) | 48-VQFN (6x6) |
Synchronous Rectifier | False | False |
Topology | Buck | Buck |
Voltage - Supply (Vcc/Vdd) [Max] | 18 V | 18 V |
Voltage - Supply (Vcc/Vdd) [Min] | 4.5 V | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
TPS536C7 Series
Dual-channel D-CAP+™, PMBus (N+M ≤ 12 phases) step-down, multiphase PWM controller
Part | Topology | Voltage - Supply (Vcc/Vdd) [Min] | Voltage - Supply (Vcc/Vdd) [Max] | Number of Outputs | Duty Cycle (Max) [Max] | Frequency - Switching [Max] | Frequency - Switching [Min] | Mounting Type | Synchronous Rectifier | Output Type | Clock Sync | Output Configuration | Control Features | Package / Case | Supplier Device Package | Serial Interfaces | Function | Operating Temperature [Min] | Operating Temperature [Max] |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments TPS536C7B1RSLTBuck Regulator Positive Output Step-Down PMBus DC-DC Controller IC 48-VQFN (6x6) | Buck | 4.5 V | 18 V | 1 | 50 % | 2 MHz | 300 kHz | Surface Mount | Transistor Driver | Positive | Current Limit, Enable, Frequency Control, Phase Control, Ramp | 48-VFQFN Exposed Pad | 48-VQFN (6x6) | PMBus | Step-Down | -40 °C | 125 °C | ||
Texas Instruments TPS536C7B1RSLRBuck Regulator Positive Output Step-Down PMBus DC-DC Controller IC 48-VQFN (6x6) | Buck | 4.5 V | 18 V | 1 | 50 % | 2 MHz | 300 kHz | Surface Mount | Positive | Current Limit, Enable, Frequency Control, Phase Control, Ramp, Soft Start | 48-VFQFN Exposed Pad | 48-VQFN (6x6) | PMBus | Step-Down | -40 °C | 125 °C |
