MAXREFDES111C#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR MAX17498B
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXREFDES111C#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR MAX17498B
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXREFDES111C# | MAXREFDES111 Series |
|---|---|---|
| Board Type | Fully Populated | Fully Populated |
| Current - Output | 400 mA | 400 mA |
| Frequency - Switching | 500 kHz | 500 kHz |
| Main Purpose | DC/DC Converter | DC/DC Converter |
| Outputs and Type | Isolated | Isolated |
| Outputs and Type | 1 | 1 |
| Power - Output | 2 W | 2 W |
| Regulator Topology | Flyback | Flyback |
| Supplied Contents | Board(s) | Board(s) |
| Utilized IC / Part | MAX17498B | MAX17498B |
| Voltage - Input [Max] | 36 V | 36 V |
| Voltage - Input [Min] | 18 V | 18 V |
| Voltage - Output | 5 V | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 23.59 | |
MAXREFDES111 Series
EVAL BOARD FOR MAX17498B
| Part | Power - Output | Frequency - Switching | Utilized IC / Part | Voltage - Output | Outputs and Type | Outputs and Type | Current - Output | Regulator Topology | Supplied Contents | Main Purpose | Board Type | Voltage - Input [Max] | Voltage - Input [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXREFDES111B# | 2 W | 500 kHz | MAX17498B | 5 V | Isolated | 1 | 400 mA | Flyback | Board(s) | DC/DC Converter | Fully Populated | 36 V | 18 V |
Analog Devices Inc./Maxim Integrated MAXREFDES111C# | 2 W | 500 kHz | MAX17498B | 5 V | Isolated | 1 | 400 mA | Flyback | Board(s) | DC/DC Converter | Fully Populated | 36 V | 18 V |
Description
General part information
MAXREFDES111 Series
MAX17498B - DC/DC Converter 1, Isolated Outputs Evaluation Board
