A9PS16-0011

Active

Omron Electronics Inc-EMC Div

SWITCH PUSH SPST-NO 0.1A 28V

Search across all available documentation for this part.

Active

Omron Electronics Inc-EMC Div

SWITCH PUSH SPST-NO 0.1A 28V

Technical Specifications

Parameters and characteristics for this part

Specification	A9PS16-0011

Actuator Marking	No Marking
Actuator Type	Plunger for Cap
Circuit	SPST-NO
Current Rating (Amps)	100 mA
Electrical Life	50000 Cycles
Features	Sealed - Flux Protection
Ingress Protection	IP64 - Dust Tight, Water Resistant
Mounting Type	Through Hole
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Switch Function	Off-Mom
Termination Style	PC Pin
Type	Standard
Voltage Rating - AC	28 V
Voltage Rating - DC	28 V

Part	Circuit	Termination Style	Current Rating (Amps)	Actuator Marking	Voltage Rating - DC	Features	Mounting Type	Electrical Life	Type	Actuator Type	Ingress Protection	Switch Function	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]
Omron Electronics Inc-EMC Div A9PS26-0012	DPST-NO	PC Pin	100 mA	No Marking	28 V	Sealed - Flux Protection	Through Hole Right Angle	50000 Cycles	Standard	Plunger for Cap	IP64 - Dust Tight Water Resistant	Off-Mom	28 V	-20 C	80 C
Omron Electronics Inc-EMC Div A9PS16-0011	SPST-NO	PC Pin	100 mA	No Marking	28 V	Sealed - Flux Protection	Through Hole	50000 Cycles	Standard	Plunger for Cap	IP64 - Dust Tight Water Resistant	Off-Mom	28 V	-20 C	80 C
Omron Electronics Inc-EMC Div A9PS16-0012	SPST-NO	PC Pin	100 mA	No Marking	28 V	Sealed - Flux Protection	Through Hole Right Angle	50000 Cycles	Standard	Plunger for Cap	IP64 - Dust Tight Water Resistant	Off-Mom	28 V	-20 C	80 C
