5508UE 008U1000

Active

Belden Inc.

CABLE 10COND 22AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 10COND 22AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	5508UE 008U1000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	5.44 mm
Jacket (Insulation) Diameter [diameter]	0.214 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.457 mm
Jacket (Insulation) Thickness	0.018 in
Jacket Color	Gray
Length	1000 ft
Length	304.8 m
Number of Conductors	10
Ratings	UL Style CMR
Usage	Sound, Security
Voltage	300 V
Wire Gauge	22 AWG

Part	Wire Gauge	Conductor Insulation	Ratings	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Usage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Jacket Color	Length	Length	Features	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Cable Type	Jacket (Insulation) Material
Belden Inc. 5508UE 0081000	22 AWG	Polypropylene (PP)	UL Style CMR	7	30 AWG	300 V	Security Sound	5.44 mm	0.214 in	10	Gray	1000 ft	304.8 m	Rip Cord	0.457 mm	0.018 in	Copper Bare	Multi-Conductor	Poly-Vinyl Chloride (PVC) Riser
Belden Inc. 5508UE 008U1000	22 AWG	Polypropylene (PP)	UL Style CMR	7	30 AWG	300 V	Security Sound	5.44 mm	0.214 in	10	Gray	1000 ft	304.8 m	Rip Cord	0.457 mm	0.018 in	Copper Bare	Multi-Conductor	Poly-Vinyl Chloride (PVC) Riser

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.41

General part information

10 Conductor Multi-Conductor Cable Gray 22 AWG 1000.0' (304.8m)
