ESK227M050AH1AA

Active

KEMET

CAP ALUM 220UF 20% 50V RADIAL TH

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 220UF 20% 50V RADIAL TH

Technical Specifications

Parameters and characteristics for this part

Part	Capacitance	Package / Case	Lead Spacing	Lead Spacing	Ripple Current @ Low Frequency	Lifetime @ Temp.	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Tolerance	Polarization	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage - Rated	Mounting Type	Ripple Current @ High Frequency	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max)
KEMET ESK227M6R3AC3AA	220 µF	Radial Can	2 mm	0.079 in	200 mA	2000 Hrs	0.492 in	12.5 mm	20 %	Polar	5 mm	0.197 "	6.3 V	Through Hole	240 mA	General Purpose	85 °C	-40 °C
KEMET ESK227M016AG3DA	220 µF	Radial Can	3.5 mm	0.138 in		2000 Hrs	0.492 in	12.5 mm	20 %	Polar	8 mm	0.315 "	16 V	Through Hole		General Purpose	85 °C	-40 °C
KEMET ESK227M025AG3EA	220 µF	Radial Can	3.5 mm	0.138 in	290 mA	2000 Hrs	0.492 in	12.5 mm	20 %	Polar	8 mm	0.315 "	25 VDC	Through Hole	348 mA	General Purpose	85 °C	-40 °C
KEMET ESK227M063AH2AA	220 µF	Radial Can	5 mm	0.197 in	410 mA	2000 Hrs			20 %	Polar	10 mm	0.394 in	63 V	Through Hole	492 mA	General Purpose	85 °C	-40 °C	17 mm	0.669 in
KEMET ESK227M050AH1EA	220 µF	Radial Can	5 mm	0.197 in		2000 Hrs			20 %	Polar	10 mm	0.394 in	50 VDC	Through Hole		General Purpose	85 °C	-40 °C		0.531 "	13.5 mm
KEMET ESK227M050AH9KA	220 µF	Radial Can	5 mm	0.197 in	380 mA	2000 Hrs	0.551 "		20 %	Polar	10 mm	0.394 in	50 VDC	Through Hole	456 mA	General Purpose	85 °C	-40 °C			14 mm
KEMET ESK227M050AH1AA	220 µF	Radial Can	5 mm	0.197 in		2000 Hrs			20 %	Polar	10 mm	0.394 in	50 VDC	Through Hole		General Purpose	85 °C	-40 °C		0.531 "	13.5 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

220 µF 50 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C
