SGD-120-3

Active

TE Connectivity Measurement Specialties

SENSOR LINEAR 3048MM CONNECTOR

Search across all available documentation for this part.

Active

TE Connectivity Measurement Specialties

SENSOR LINEAR 3048MM CONNECTOR

Technical Specifications

Parameters and characteristics commom to parts in this series

SENSOR LINEAR 3048MM CONNECTOR

Part	For Measuring	Termination Style	Linear Range [Max]	Linear Range [Min]	Linear Range [Min]	Linear Range [Max]	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Technology	Actuator Type	Output [Min]	Output [Max]	Resistance	Resistance Tolerance	Mounting Type	Package / Case
TE Connectivity Measurement Specialties SGD-120-3	Linear Position	Connector	120 in	0 mm	0 in	3048 mm	8 V	40 VDC	70 °C	-18 °C	Resistive	String Potentiometer	4	20 mA	10000 Ohms	10%	Custom	Box with Connector
TE Connectivity Measurement Specialties SGD-80-3	Linear Position	Connector	80 in	0 mm	0 in	2032 mm	8 V	40 VDC	70 °C	-18 °C	Resistive	String Potentiometer	4	20 mA	10000 Ohms	10%	Custom	Box with Connector

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Resistive Sensor Linear Position String Potentiometer Connector
