CG-PG16-1-BK

Active

Essentra Access Solutions

CABLE GLAND, PG16, 10 MM, 14 MM, NYLON 6 (POLYAMIDE 6), BLACK, IP68

Search across all available documentation for this part.

Active

Essentra Access Solutions

CABLE GLAND, PG16, 10 MM, 14 MM, NYLON 6 (POLYAMIDE 6), BLACK, IP68

Technical Specifications

Parameters and characteristics for this part

Specification	CG-PG16-1-BK

Color	Black
Includes	Sealing Gland, Sealing Nut
Ingress Protection	IP68 - Dust Tight, Waterproof
Material	Polyamide (PA), Nylon
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-20 C
Outside Cable Diameter (Max) [Max]	14 mm
Outside Cable Diameter (Max) [Max]	0.551 "
Outside Cable Diameter (Min) [Min] [diameter]	0.394 in
Outside Cable Diameter (Min) [Min] [diameter]	10 mm
Panel Hole Size	0.898 ", 22.8 mm
Thread Length	10 mm
Thread Length	0.394 in
Thread Size	PG16
Type	Cable Gland

Part	Thread Size	Type	Color	Outside Cable Diameter (Max) [Max]	Outside Cable Diameter (Max) [Max]	Panel Hole Size	Operating Temperature [Max]	Operating Temperature [Min]	Thread Length	Thread Length	Ingress Protection	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min) [Min] [diameter]	Includes	Material
Essentra Access Solutions CG-PG16-1-BK	PG16	Cable Gland	Black	14 mm	0.551 "	0.898 " 22.8 mm	100 °C	-20 C	10 mm	0.394 in	IP68 - Dust Tight Waterproof	0.394 in	10 mm	Sealing Gland Sealing Nut	Polyamide (PA) Nylon

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Gland Polyamide (PA), Nylon PG16 Black
