31518 010500

Active

Belden Inc.

HOOK-UP STRND 18AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 18AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	31518 010500

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	16
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.109 "
Jacket (Insulation) Diameter [diameter]	2.77 mm
Jacket (Insulation) Material	Neoprene
Jacket (Insulation) Thickness	0.84 mm
Jacket (Insulation) Thickness	0.033 in
Jacket Color	Black
Length [x]	500 '
Length [x]	152.4 m
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-30 ░C
Ratings	UL Style 3044
Voltage	300 V
Wire Gauge	18 AWG

Part	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Cable Type	Jacket Color	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Voltage	Jacket (Insulation) Material	Length [x]	Length [x]
Belden Inc. 31518 0105000	18 AWG	16	30 AWG	Hook-Up	Black	-30 ░C	90 °C	0.84 mm	0.033 in	UL Style 3044	0.109 "	2.77 mm	Copper Tinned	300 V	Neoprene
Belden Inc. 31518 0065000	18 AWG	16	30 AWG	Hook-Up	Blue	-30 ░C	90 °C	0.84 mm	0.033 in	UL Style 3044	0.109 "	2.77 mm	Copper Tinned	300 V	Neoprene
Belden Inc. 31518 0095000	18 AWG	16	30 AWG	Hook-Up		-30 ░C	90 °C	0.84 mm	0.033 in	UL Style 3044	0.109 "	2.77 mm	Copper Tinned	300 V	Neoprene
Belden Inc. 31518 010500	18 AWG	16	30 AWG	Hook-Up	Black	-30 ░C	90 °C	0.84 mm	0.033 in	UL Style 3044	0.109 "	2.77 mm	Copper Tinned	300 V	Neoprene	500 '	152.4 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 0.73

General part information

18 AWG Hook-Up Wire 16/30 Black 300V 500.0' (152.4m)
